Paper Title:
Research on the Plunge Milling Techniques for Open Blisks
  Abstract

In order to improve the efficiency and quality in rough milling for open blisks, the plunge milling strategy is a good choice instead of the traditional 5-axis point milling and flank milling for deep and narrow channels machining. Theory and procedures of using a ruled surface to approximate a freeform surface are presented based on the theory of minimum area. The plunge milling strategy is discussed and developed for open blisks. And the NC programs of plunge milling is further developed and verified based on the UG software. At the end, the open blisk test piece was machined by plunge milling. The result reveals that high-speed plunge milling has increased efficiency greatly in the open blisks rough milling than the traditional methods.

  Info
Periodical
Materials Science Forum (Volumes 532-533)
Edited by
Chengyu Jiang, Geng Liu, Dinghua Zhang and Xipeng Xu
Pages
193-196
DOI
10.4028/www.scientific.net/MSF.532-533.193
Citation
C. W. Shan, D. H. Zhang, J. X. Ren, C. G. Hu, "Research on the Plunge Milling Techniques for Open Blisks", Materials Science Forum, Vols. 532-533, pp. 193-196, 2006
Online since
December 2006
