Paper Title:
Variable Radius Conformal Cooling Channel for Rapid Tool
  Abstract

The cooling system of a plastic injection mould is important as it affects the quality and productivity of the polymeric components or assemblies. Contemporary cooling channel design is confined to simple configurations of straight-drilled coolant passageway around the mould insert. Undesirable defects resulted during injection moulding, such as warpage, are inevitable. The application of rapid tool (RT) based on solid freeform fabrication (SFF) technologies with conformal cooling channel (CCC) design has provided a profound opportunity in quality improvement of polymeric components. In this study, a novel design of variable radius conformal cooling channel (VRCCC) is proposed to achieve better uniform cooling performance. Thermal-FEA and melt flow analysis are used to validate the method.

  Info
Periodical
Materials Science Forum (Volumes 532-533)
Edited by
Chengyu Jiang, Geng Liu, Dinghua Zhang and Xipeng Xu
Pages
520-523
DOI
10.4028/www.scientific.net/MSF.532-533.520
Citation
K. M. Au, K. M. Yu, "Variable Radius Conformal Cooling Channel for Rapid Tool", Materials Science Forum, Vols. 532-533, pp. 520-523, 2006
Online since
December 2006
