Paper Title:
Development of Welding Distortion Analysis Method Using Residual Strain as Boundary Condition
  Abstract

There are two ways of conventional thermal distortion analysis. One is thermal elastoplastic analysis and the other is equivalent forces method based on inherent strain. The former needs exorbitant analysis time, while the latter cannot obtain stress results and requires more time with loads modeling on curved plates. To solve those time-consuming problems, a new kind of thermal distortion analysis method was developed. In this method, inherent strains are devised to be used as direct input factors as boundary conditions. Suggested analysis method was already adopted at welding distortion analysis of large hull block, which was considered as impossible.

  Info
Periodical
Materials Science Forum (Volumes 580-582)
Edited by
Changhee Lee, Jong-Bong Lee, Dong-Hwan Park and Suck-Joo Na
Pages
649-654
DOI
10.4028/www.scientific.net/MSF.580-582.649
Citation
Y. S. Ha, S. H. Cho, T. W. Jang, "Development of Welding Distortion Analysis Method Using Residual Strain as Boundary Condition", Materials Science Forum, Vols. 580-582, pp. 649-654, 2008
Online since
June 2008
Export
Price
$32.00
