Paper Title:
Fast Switching Characteristics of 4H-SiC RESURF-Type JFET
  Abstract

400V/2.5A 4H-SiC JFETs having a reduced surface field (RESURF) structure were fabricated. Measurements on the static and switching characteristics were carried out. The on-resistance was 0.86 W. The turn-on time (ton) and the turn-off time (toff) were 8ns and 10 ns, respectively. The fabricated JFETs showed low on-resistance and fast switching characteristics. 4H-SiC RESURF-type JFETs, which is a sort of lateral transistor, are preferable to a module configuration of switching devices. Moreover, they are promising for application to DC power supplies with higher efficiency and smaller size owing to their low on-resistance and fast switching characteristics.

  Info
Periodical
Materials Science Forum (Volumes 600-603)
Edited by
Akira Suzuki, Hajime Okumura, Tsunenobu Kimoto, Takashi Fuyuki, Kenji Fukuda and Shin-ichi Nishizawa
Pages
1095-1098
DOI
10.4028/www.scientific.net/MSF.600-603.1095
Citation
K. Fujikawa, K. Sawada, T. Tsuno, H. Tamaso, S. Harada, Y. Namikawa, "Fast Switching Characteristics of 4H-SiC RESURF-Type JFET ", Materials Science Forum, Vols. 600-603, pp. 1095-1098, 2009
Online since
September 2008
