Paper Title:
Device Characteristics Dependence on Diamond SDBs Area
  Abstract

Device size scaling of pseudo-vertical diamond Schottky barrier diodes (SBDs) has been characterized for high-power device applications based on the control of doping concentration and thickness of the p- CVD diamond layer. Decreasing parasitic resistance on the p+ layer utilizing lithography and etching makes possible to get a constant specific on-resistance of less than 20 mOhm-cm2 with increasing device size up to 200 µm. However, the leakage current under low reverse bias conditions is increased markedly. Due to the increase in the leakage current, the reverse operation limit is decreased from 2.4 to 1.3 MV/cm when the device size is increased from 30 to 150 µm. If defects induce an increase in leakage current under the reverse conditions, the density of the defects can be estimated to be 104–105/cm2. This value is 5–10 times larger than the density of dislocations in single crystal diamond substrate.

  Info
Periodical
Materials Science Forum (Volumes 615-617)
Edited by
Amador Pérez-Tomás, Philippe Godignon, Miquel Vellvehí and Pierre Brosselard
Pages
1003-1006
DOI
10.4028/www.scientific.net/MSF.615-617.1003
Citation
H. Umezawa, K. Ikeda, R. Kumaresan, N. Tatsumi, S. Shikata, "Device Characteristics Dependence on Diamond SDBs Area", Materials Science Forum, Vols. 615-617, pp. 1003-1006, 2009
