Paper Title:
100 Amp, 1000 Volt Class 4H-Silicon Carbide MOSFET Modules
  Abstract

The development of large area, up to 70m/1kV (0.45cm x 0.45cm) 4H-SiC vertical DMOSFETs is presented. DC and switching characteristics of high-current, 100Amp All-SiC power switching modules are demonstrated using 0.45cm x 0.225cm DMOSFET die and commercial Schottky diodes. The switching performance from room temperature up to T=200°C of the All-SiC modules is presented, with as much as ten times lower losses than co-fabricated Si-based modules using commercial IGBTs.

  Info
Periodical
Materials Science Forum (Volumes 615-617)
Edited by
Amador Pérez-Tomás, Philippe Godignon, Miquel Vellvehí and Pierre Brosselard
Pages
899-902
DOI
10.4028/www.scientific.net/MSF.615-617.899
Citation
P. A. Losee, K. Matocha, S. Arthur, E. Delgado, R. Beaupre, A. Pautsch, R. R. Rao, J. Nasadoski, J. L. Garrett, Z. Stum, L. Stevanovic, R. A. Conte, K. Monaghan, "100 Amp, 1000 Volt Class 4H-Silicon Carbide MOSFET Modules", Materials Science Forum, Vols. 615-617, pp. 899-902, 2009
Online since
March 2009
