Paper Title:
A New One-Side Finish Machining Method for Profile of Globoidal Indexing Cam in High Speed
  Abstract

A new one-side finish machining method for the profile of globoidal indexing cam in high speed, which modifies the tool path of traditional enveloping method, was put forward. The new method is useful for overcoming the defects caused by traditional enveloping method, can realize one-side machining of globoidal indexing cam, can improve the machined surface quality and the meshing characteristics of the cam mechanism. The practical calculation formulas of tool path modification is given, which can be used in developing the CAD/CAM software of the globoidal indexing cam. The new method has great practical value.

  Info
Periodical
Materials Science Forum (Volumes 626-627)
Edited by
Dongming Guo, Jun Wang, Zhenyuan Jia, Renke Kang, Hang Gao, and Xuyue Wang
Pages
611-616
DOI
10.4028/www.scientific.net/MSF.626-627.611
Citation
X.F. Tang, W. He, Y.S. Liu, "A New One-Side Finish Machining Method for Profile of Globoidal Indexing Cam in High Speed", Materials Science Forum, Vols. 626-627, pp. 611-616, 2009
Online since
August 2009
