Paper Title:
Research and Application on Heterogeneous CAD Platforms of Modular Fixture System
  Abstract

Application on multi-platforms for a computer-aided fixture design (CAFD) system is significant. But now, relative less attention is focused on this direction. On above backgrounds, research was carried out on data construction, data description, data conversation as well as data parsing. In modular fixture system, components in the modular fixture base were described according to their CSG-based primitives. So, XML was used to represent the simple data because of its widely using on net and different operational systems. By developing interfaces between diverse CAD systems, the modular fixture system can be applied on heterogeneous environments and reinventing the wheel can be avoided.

  Info
Periodical
Materials Science Forum (Volumes 697-698)
Chapter
III. Digital Manufacturing System and Management
Edited by
Tian Huang, Dawei Zhang, Bin Lin, Anping Xu, Yanling Tian and Weiguo Gao
Pages
503-507
DOI
10.4028/www.scientific.net/MSF.697-698.503
Citation
J. Cai, H.X. Liu, G.L. Duan, "Research and Application on Heterogeneous CAD Platforms of Modular Fixture System", Materials Science Forum, Vols. 697-698, pp. 503-507, 2012
Online since
September 2011
