Paper Title:
Finite Element Analysis of Crawler Frame of the Rotary Drill Bits
  Abstract

Commercial finite element modeling software ANSYS was used to calculate the stress and deformation distributions of crawler frame of the Rotary drill bits under turning work condition. By using finite element method, the weak points of the crawler frame can be found and the strength of the model can be calculated quickly and correctly. The results show that the crawler frame has enough strength to support the machine to finish the turning process and the maximum displacement distributed in the middle of the crawler frame. This paper will supply references for the structural optimize design of crawler frame of the rotary drill bits.

  Info
Periodical
Materials Science Forum (Volumes 697-698)
Chapter
IV. Modern Design Theory and Methodology
Edited by
Tian Huang, Dawei Zhang, Bin Lin, Anping Xu, Yanling Tian and Weiguo Gao
Pages
712-716
DOI
10.4028/www.scientific.net/MSF.697-698.712
Citation
Y. Sun, Y.Q. Yang, "Finite Element Analysis of Crawler Frame of the Rotary Drill Bits", Materials Science Forum, Vols. 697-698, pp. 712-716, 2012
Online since
September 2011
