Paper Title:
Identification of Bolt Connection Parameters for Vertical Grinding Machine in CAD/CAE Environment
  Abstract

Dynamic analysis and modal test were conducted on a vertical grinding machine. The mathematical model of joint surface parameter identification between the bed and the column was established in CAD/CAE integrated environment. Based on the results of dynamic analysis and modal test, the parameters of joint surface were identified and the finite element model was accurately created. Then, the weak bodies of the original machine were improved. According to the finite element analysis of the improved machine, the performances of the new machine were better than the original machine.

  Info
Periodical
Materials Science Forum (Volumes 697-698)
Chapter
I. Advanced Manufacturing Technology and Equipment
Edited by
Tian Huang, Dawei Zhang, Bin Lin, Anping Xu, Yanling Tian and Weiguo Gao
Pages
97-101
DOI
10.4028/www.scientific.net/MSF.697-698.97
Citation
C. H. Wang, Y. L. Chen, J. P. Pang, D. W. Zhang, G.X. Pan, "Identification of Bolt Connection Parameters for Vertical Grinding Machine in CAD/CAE Environment", Materials Science Forum, Vols. 697-698, pp. 97-101, 2012
Online since
September 2011
