Paper Title:
Modeling of Magnetic Attraction Force of Electromagnetic Module in a Relative Base – Air-Gap – Absolute Base System
  Abstract

In this paper a formula of estimation of magnetic attraction force in the relative base – air-gap – absolute base system is presented. The attraction force of the relative base (forcer) to the ferromagnetic absolute base (stator) is a result of the attraction of permanent magnets, which are the components of the electromagnetic modules. The physical model and mathematical description of the particular electromagnetic module are presented.

  Info
Periodical
Solid State Phenomena (Volume 144)
Edited by
Inga Skiedraite and Jolanta Baskutiene
Pages
53-58
DOI
10.4028/www.scientific.net/SSP.144.53
Citation
T. Huścio, K. Falkowski, "Modeling of Magnetic Attraction Force of Electromagnetic Module in a Relative Base – Air-Gap – Absolute Base System", Solid State Phenomena, Vol. 144, pp. 53-58, 2009
Online since
September 2008
Export
Price
$32.00
