Paper Title:
Inclined Axis Ultra-Precision Grinding for Spherical Surface
  Abstract

Through establishing the mathematical models of velocity and grinding force to optimize the installation angle with inclined axis grinding technology, the spherical surface of the ultra-hard alloy material was ground by formed electroplated diamond wheel. After analyzing the abrasion of grinding wheel, the results show that the inclined axis grinding technology of the formed grinding wheel can avoid the rotation dead spots of grinding wheel, and can make the grinding wheel surface contacted with work-piece fully which could make the worn more evenly. Finally, it obtains a surface in a high quality with the surface roughness of Ra is 12.88nm, and the form accuracy of PV is 124nm.

  Info
Periodical
Solid State Phenomena (Volume 175)
Edited by
Xipeng Xu
Pages
145-149
DOI
10.4028/www.scientific.net/SSP.175.145
Citation
S. H. Yin, J. Wang, F. J. Chen, J. W. Yu, Y. Wang, Q. L. Zhao, H. L. Li, "Inclined Axis Ultra-Precision Grinding for Spherical Surface", Solid State Phenomena, Vol. 175, pp. 145-149, 2011
Online since
June 2011
Export
Price
$32.00
Share
