Creation of Adaptive-Mechanical Continuously Variable Transmission

Abstract:

Recently there were patents on not switched gear continuously variable transmission (CVT) without hydro transformer. In transmission wheelwork with two degrees of freedom and one entrance is used. Adaptive mechanism of CVT provides possibility of output link movement with speed inversely to resistance force at constant input power. However the theoretical description of such transmissions is not convincing enough. Obviously at the basis of creation of adaptive transfers with two degrees of freedom essentially new regularity of mechanics lies. Purpose of present work is to formulate regularities of the mechanics allowing creating the adaptive-mechanical continuously variable transmission. The using of the found regularities will allow creating transmissions with mechanical adaptation to variable technological loading.

Info:

Periodical:

Applied Mechanics and Materials (Volume 436)

Edited by:

Adrian Olaru

Pages:

63-70

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.436.63

Citation:

Cite this paper

Online since:

October 2013

Authors:

Konstantin Samson Ivanov

Keywords:

Adaptive Mechanism, Closed Contour, Continuously Variable Transmission

Export:

RIS, BibTeX

Price:

Permissions:

Request Permissions

References

[1] Levitskiy N.I. Theory of mechanisms and machines. M., Science. (1979), p.576.

[2] Samuel J. Crockett. Shiftless, continuously-aligning transmission. Patent of USA 4, 932, 928, Cl. F16H 47/08, U.S. Cl. 475/51; 475/47. (1990), p.9.

[3] Volkov I.V. Way of automatic and continuous change of a twisting moment and speed of twirl of the output shaft depending on a tractive resictance and the device for its realisation. The invention description to the patent of Russia RU 2 234 626. (2004).

[4] Harries John. Force transmission system comprising two sets of epicyclic gears. Patent of Great Britain GB2238090 (A). (1991), p.11.

[5] Ivanov K.S., Jaroslavceva E.K. Way of automatic and continuous change of a twisting moment and speed of twirl of the output shaft depending on a tractive resictance and the device for its realisation. Patent of Russia RU № 2398989. (2010), p.16.

[6] Konstantin S. Ivanov K.S. Almaty, KAZ - Owner of the registered sample. The name - Device of automatic and continuous change of a twisting moment – and changes of a corrected speed of output shaft depending on a tractive resistance. The deed on registration of the registered sample № 20 2012 101 273. 1. Day of Registration 02. 05. 2012. The German patent and firm establishment. Federal Republic Germany. 2012. 12 p.

[7] Ivanov K.S. Paradox of mechanics – a basis of creation CVT. Transactions of 2-d IFToMM Asian Conference on Mechanisms and Machines Science. November 7-10, 2012, Tokyo, Japan. P. 245 – 264.

[8] Ivanov K.S. Effect of force adaptation in mechanics. Journal of Mechanics Engineering and Automation. Vol. 1, N 3. Libertiville, USA. 2011. P. 163 – 180.
