Experimental Research on Phase-Change Cooling for High-Power Chip

Abstract:

Phase change cooling technology is based on the boiling of refrigerating medium to absorb the heat generated by the electronic chip. It provides higher heat flux dissipation, reduces the refrigerating medium flux and consumes a lower pumping power, compared with single-phase liquid cooling. It also has good temperature uniformity and higher working temperature, which is ideal for energy reuse. Experimental system was designed for phase change cooling of R123 to analyze the basic conditions required for boiling vaporization. The chip temperature was 70 °C or less when the heat flux was 100 W·cm^-2, with the 0.6 mm rectangular micro-channel evaporator. Experiments were conducted to analyze the effects of heat flux, channel dimension, throttling action on the heat transfer effect.

• Periodical: Applied Mechanics and Materials (Volume 628)
• Pages: 306-310
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.628.306
• Online since: September 2014
• Authors: Long Sheng Wu, Xu Zhang, Cheng Jian Wang, Zhen Long Wang*
• Keywords: High Performance Computer, High-Power Chip, Micro-Channel, Phase Change Cooling

References

[1] Ellsworth M J, Campbell L A, Simons R E, et al. The evolution of water cooling for IBM large server systems: Back to the future[C]. Thermal and Thermomechanical Phenomena in Electronic Systems, 2008. ITHERM 2008. 11th Intersociety Conference on. IEEE, 2008: 266-274.

DOI: 10.1109/itherm.2008.4544279

[2] Marcinichen J B, Thome J R, Michel B. Cooling of microprocessors with micro-evaporation: A novel two-phase cooling cycle[J]. International Journal of Refrigeration, 2010, 33(7): 1264-1276.

DOI: 10.1016/j.ijrefrig.2010.06.008

[3] Agostini B, Fabbri M, Park J E, et al. State of the art of high heat flux cooling technologies[J]. Heat Transfer Engineering, 2007, 28(4): 258-281.

DOI: 10.1080/01457630601117799

[4] Zhang Xu, Chen Yu-jun. Study on phase change cooling technology for high performance computer[J]. High performance computing technology, 2008, (3): 11-14 (in Chinese).

[5] Madhour Y, Olivier J, Costa-Patry E, et al. Flow boiling of R134a in a multi-microchannel heat sink with hotspot heaters for energy-efficient microelectronic CPU cooling applications[J]. Components, Packaging and Manufacturing Technology, IEEE Transactions on, 2011, 1(6): 873-883.

DOI: 10.1109/tcpmt.2011.2123895

[6] Hannemann R, Marsala J, Pitasi M. Pumped liquid multiphase cooling[C]. ASME 2004 International Mechanical Engineering Congress and Exposition. American Society of Mechanical Engineers, 2004: 469-473.

DOI: 10.1115/imece2004-60669

[7] Trutassanawin S, Groll E A, Garimella S V, et al. Experimental investigation of a miniature-scale refrigeration system for electronics cooling[J]. Components and Packaging Technologies, IEEE Transactions on, 2006, 29(3): 678-687.

DOI: 10.1109/tcapt.2006.881762

[8] Thome J R, Bruch A. Refrigerated cooling of microprocessors with micro-evaporation heat sinks: new development and energy Conservation Prospects for green datacenters[J]. Proceedings Institute of refrigeration (IOR), (2008).

[9] Mauro A W, Thome J R, Toto D, et al. Saturated critical heat flux in a multi-microchannel heat sink fed by a split flow system[J]. Experimental Thermal and Fluid Science, 2010, 34(1): 81-92.

DOI: 10.1016/j.expthermflusci.2009.09.005

[10] Yang Shiming, Tao Wenquan. Heat transfer theory[M]. Beijing: Higher education press, 2005: 215-225 (in Chinese).
