Analytic Prediction of Structural Stress-Strain Relations of Microstructured Metal
Nanostructured and ultra-fine grained metals have higher strength but extremely limited ductility compared to coarse grained metals. However, their ductility can be greatly improved by introducing a specific range of grain sizes in the microstructures. In the paper, multiscale unit cell approach (UCA) is developed and applied to predict the averaged stress-strain relations of the multiscale microstructure metals. The unit cell models are three-phase structured at different scale lengths of 100 nm, 1 μm and 10 μm with different volume fractions and periodic boundary conditions. The contributions of multi-scale microstructures to the macroscopic structural properties of metals are also studied using a analytic approach—two-step mean-field method (TSMF), where three microstructural parameters are introduced and thus mechanical properties such as strength and ductility are presented as a function of these parameters. For verification of these proposed numerical and theoretical algorithms, the structural properties of the pure nickel with three-grain microstructures are studied and the results from FEA and the proposed theory have good agreement.
John Bell, Cheng Yan, Lin Ye and Liangchi Zhang
C. H. Yang et al., "Analytic Prediction of Structural Stress-Strain Relations of Microstructured Metal", Advanced Materials Research, Vol. 32, pp. 83-86, 2008
