Preparation of Thin and Powdered Radioactive Samples for Electron Microscopy and X-Ray Diffraction Analysis of Radiation-Induced Damage

Abstract:

Research and development of materials in the nuclear industry, including the assessment of irradiated components in nuclear power plants, rely heavily on research infrastructures that facilitate the preparation and analysis of radioactive samples. The metallographic preparation of samples must be carried out in shielded, hermetically sealed boxes and hot cells, as a large amount of dusty radioactive particles is released during the sample preparation process. Small samples, thin films for scanning and transmission electron microscopy (SEM, TEM), and powdered samples from biological shielding concretes are prepared in glove boxes, where a constant negative pressure is maintained. The enclosures of the boxes are constructed of thick-walled steel plates to shield against the ionizing radiation emitted by radioactive samples, protecting personnel. Subsequent microscopic analyses allow for the assessment of material degradation in operational nuclear power plant components caused by radiation-induced microstructure damage. These analyses focus both on existing materials, with the aim of extending the lifespan of nuclear power plants, and on newly tested materials irradiated as part of domestic and international programs, including those conducted at research reactors like LVR-15, operated by the Řež Research Center (CVŘ). Different analytical requirements call for the preparation of various types of samples. At CVŘ, X-ray diffraction analysis of powdered samples is primarily used to evaluate structural and phase changes in the cement and aggregate of concrete structures caused by radiation aging, which can impact the overall integrity of the structure. Monitoring these changes and predicting material behavior are essential for evaluating the safety, stability and durability of concrete used in biological shielding, containment structures, spent nuclear fuel storage pools and future deep radioactive waste repositories. Thin films for electron microscopy are prepared specifically to assess detailed changes, such as radiation-induced microstructure damage in reactor internals or fuel cladding, which result in dimensional changes and the degradation of mechanical properties due to neutron radiation.

• Periodical: Key Engineering Materials (Volume 1034)
• Pages: 119-125
• DOI: https://doi.org/10.4028/p-K93Ywt
• Online since: December 2025
• Authors: Vít Rosnecký*, Claudia Aparicio, Oksana Nechypor, Patricie Halodová, Petra Gávelová, Zdeněk Fencl
• Keywords: Electron Microscopy, Gamma Radiation, Neutron Radiation, Radiation Damage, Shielded Glove Box, X-Ray Diffraction

References

[1] I. Maruyama, T. Kondo, S. Sawada, P. Halodová, A. Fedoriková, T. Ohkubo, K. Murakami, T. Igari, E. Tajuelo Rodriguez, K. Suzuki, Radiation-induced Alteration of Meta-chert, Journal of Advanced Concrete Technology 2022, 20 (12), 760-776.

DOI: 10.3151/jact.20.760

[2] Y. Khmurovska, A. Fedoriková, C. O. Aparicio, P. Štemberk, Z. Hlaváč, O. Srba, Experimental and numerical investigation of radiation-induced volumetric expansion of concrete aggregates, Science Talks, Volume 6, 2023, 100208.

DOI: 10.1016/j.sctalk.2023.100208

[3] C. O. Aparicio, V. Rosnecký, P. Halodová, Simple preparation of specimens for X-ray powder diffraction analysis of radioactive materials: an illustrative example on irradiated granite Department of Material Analysis, Powder Diffr, 2024.

DOI: 10.1017/s088571562400006x

[4] S. Gates-Rector, T. Blanton, The Powder Diffraction File: A Quality Materials Characterization Database. Powder Diffr. 34 (2019), 352–360.

DOI: 10.1017/s0885715619000812

[5] M. Sathiyakumar, F. D. Gnanam, Influence of Milling Liquids and Additives on Particle Size Reduction and Sintering Behaviour of Al2O3." British Ceramic Transactions 101(5): 200–7. doi:10.1179/ 096797802225003974, 2002.

DOI: 10.1179/096797802225003974

[6] N. Döbelin, R. Kleeberg, Profex: a graphical user interface for the Rietveld refinement program BGMN. J. App. Cryst. 48 (2015), 1573-1580.

DOI: 10.1107/s1600576715014685
