Authors: G.J. Hwang, W.H. Ko
Abstract: A multi-fiber reflection displacement micrometer is developed. The device consists of a light source and a receiving fiber-array of identical fibers and photo detectors that detect the light reflected from the surface being measured. The differential output of each neighboring fiber pair is proportional to the surface displacement in a section of the total range. The light intensity variation of the source and the reflectance change of the surface are compensated when the differential output is divided by the summation output. A scale voltage is given to each output of neighboring fibers in order to shift each output to correspond to the actual displacement within the total range, which can be varied by selecting the number of fibers in the receiving fiber array. The micrometer offers the advantages of wide range, non-contact, no electrical interference, simplicity, and low cost. It can be used in medical experiments and laboratory instruments.
307
Abstract: Electrical overheating and fire are multiple faults in power system, optical fiber temperature measurement technology is better than the traditional temperature measurement device. It can test electrical system changes in temperature more effective and reliable, thus effectively contain similar accidents. This paper expounds the optical fiber temperature monitoring system warning the working principle, system constitution and its characteristics, discusses the practical application of optical fiber temperature warning monitoring system in power system.
1514
Authors: Xin Wen Duan, Ye Sun
Abstract: This paper introduces a kind of measuring system based on two-dimensional position sensitive detector PSD and single-chip signal processing, and have discussed the key technology. Two-dimensional position sensitive detector (2 D-PSD) is a kind of testing device of light spot position information and the output signal is a kind of current signal related to the location information. PSD output signal processing circuits are usually made by the I/V conversion circuit ,the addition, the subtraction and division arithmetic circuit. System can quickly, accurately and easily realize the position measurement, with a simple implementation, low power consumption, fast response, etc, It can be applied to many remote laser center positioning measurement and general industrial control occasions.
580
Authors: Weeratouch Pongruengkiat, Thitika Jungpanich, Kodchakorn Ittipornnuson, Suejit Pechprasarn, Naphat Albutt
Abstract: Refractive index and Abbe number are major physical properties of optical materials including glasses and transparent polymers. Refractive index is, in fact, not a constant number and is varied as a function of optical wavelength. The full refractive index spectrum can be obtained using a spectrometer. However, for optical component designers, three refractive indices at the wavelengths of 486.1 nm, 589.3 nm and 656.3 nm are usually sufficient for most of the design tasks, since the rest of the spectrum can be predicted by mathematical models and interpolation. In this paper, we propose a simple optical instrumental setup that determines the refractive indices at three wavelengths and the Abbe number of solid and liquid materials.
227
