Residual Deformation Measurement of Laser Weldment Using the Laser Interferometry

Abstract:

In this paper, the residual deformation induced in laser welding processing was studied by using the moiré interferometry and a novel high-temperature specimen grating technology. The experimental results indicate that the heat-affected zone of laser welding is a narrow strip. There exists great residual strain gradient in the heat-affected zone, especially great residual shear strain gradient. It implies that great residual stress and stress gradient exist near the welded seam. The relationship between the size of the heat-affected zone and the changes of the technology parameters were discussed in the experiments, which can supply some reliable experimental data for optimizing processing technology.

Info:

Periodical:

Key Engineering Materials (Volumes 326-328)

Main Theme:

Experimental Mechanics in Nano and Biotechnology

Edited by:

Soon-Bok Lee and Yun-Jae Kim

Pages:

63-66

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.326-328.63

Citation:

Z. W. Liu et al., "Residual Deformation Measurement of Laser Weldment Using the Laser Interferometry", Key Engineering Materials, Vols. 326-328, pp. 63-66, 2006

Online since:

December 2006

Authors:

Zhan Wei Liu, Da Qing Zou, Wu Zhu Chen, Wei Ning Wang, Yan Fang

Keywords:

High Temperature Grating, Laser Weldment, Residual Strains
