An Estimation Formula of the Stress Concentration Factor of the Butt-Welded Joint
The purpose of this paper is to develop an estimation formula of stress concentration factors of butt-welded components under tensile loading. To investigate the influence of weld bead profiles on stress concentration factors of double V groove butt-welded joints, butt-welded specimens were made by CO2 gas metal arc welding. And the three main parameters, the toe radius, flank angle and bead height were measured by a profile measuring equipment. By using the measured data, the influence of three parameters on the stress concentration factors was investigated by a finite element analysis. It is shown that the three parameters have similar effects on the stress concentration factors. According to the simulation results, a formula to estimate the stress concentration factors of butt-weld welded structures was proposed and the estimated concentration factors from the formula were compared with the results obtained by the finite element analysis. The two results are in a good agreement.
Yu Zhou, Shan-Tung Tu and Xishan Xie
B. C. Goo, "An Estimation Formula of the Stress Concentration Factor of the Butt-Welded Joint", Key Engineering Materials, Vols. 353-358, pp. 1995-1998, 2007
