Microfabrication of Si Column Covered with SiC Film for Electron Emitter

Abstract:

Article Preview

The selective growth of Si column was carried out by depositing Au on patterned Si (111) substrate as a solvent in chemical vapor transport method by using halides (HCl). The Si column was produced by VLS mechanism. The column was covered with SiC by conventional CVD process using HMDS ( Hexamethyldisilane ). Carbon Nano Tube ( CNT ) was deposited on Si column covered with SiC by DC assisted µ-wave plasma CVD.
