Effect of Al₃Ni and Mg₂Si Eutectic Phases on Casting Properties and Hardening of an Al-7% Zn-3% Mg Alloy

Abstract:

The formation of eutectics in Al–Zn–Mg–Ni and Al–Zn–Mg–Si systems is studied by means of metallography, DSC, EPMA, X-ray spectroscopy and thermodynamical calculations. Polythermal sections of the corresponding phase diagrams are constructed. The concentrations and temperatures of binary eutectic reactions L → (Al) + Al3Ni and L → (Al) + Mg2Si in quaternary alloys are determined. Nonequilibrium solidification in Al–7% Zn–3% Mg-based alloys ceases at approximately 480 °C. The alloys close by composition to binary eutectics have considerably improved casting properties as compared to the base Al–7% Zn–3% Mg composition. In particular, hot tearing susceptibility is much less in alloys with Al3Ni or Mg2Si. These results are corroborated by measurements of thermal contraction during solidification. The alloys containing binary eutectics exhibit much lower temperatures of contraction onset and less thermal strain is accumulated in the solidification range. Fine eutectic morphology enables fragmentation and spheroidization of intermetallic particles during annealing. The presence of Al3Ni and Mg2Si particles does not decrease the precipitation hardening effect associated with precipitation of the T′ (AlMgZn) phase. Improved casting properties and good mechanical properties of castings allow the application of Al–Zn–Mg alloys with binary eutectics formed by Al3Ni or Mg2Si as foundry alloys.

Info:

Periodical:

Materials Science Forum (Volumes 519-521)

Main Theme:

Aluminium Alloys 2006 - ICAA10

Edited by:

W.J. Poole, M.A. Wells and D.J. Lloyd

Pages:

413-418

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.519-521.413

Citation:

N. A. Belov et al., "Effect of Al₃Ni and Mg₂Si Eutectic Phases on Casting Properties and Hardening of an Al-7% Zn-3% Mg Alloy", Materials Science Forum, Vols. 519-521, pp. 413-418, 2006

Online since:

July 2006

Authors:

Nikolay A. Belov, V.V. Cheverikin, Dmitry G. Eskin, A.N. Turchin

Keywords:

Eutectic Phases, Hot Tearing, Phase Diagram, Thermal Contraction

Export:

RIS, BibTeX

Price:

$38.00

Permissions:

Request Permissions

Add to Cart

References

[1] J.E. Hatch, J.E. (Ed. ): Aluminum. Properties and Physical Metallurgy (ASM, Metals Park 1984).

[2] L. F. Mondolfo, Aluminum Alloys: Structure and Properties (Butterworths, London, 1976).

[3] N. A Belov, V.S. Zolotorevskii: Mater. Sci. Forum Vol. 396-402 (2002), p.935.

[4] E. Tagiev, S. Holiček, N. Belov: Mater. Sci. Forum Vol. 217-222 (1996), p.289.

[5] N.A. Belov, V.S. Zolotorevskii: Tsvetn. Met. No. 3 (2003), p.99.

[6] N.A. Belov, V.S. Zolotorevskii, E.E. Tagiev: Izv. Ross. Akad. Nauk, Metally No. 1 (1992), p.146.

[7] N.A. Belov, D.G. Eskin, A.A. Aksenov: Multicomponent Phase Diagrams: Applications for Commercial Aluminum Alloys (Elsevier, Amsterdam/Boston, 2005).

[8] I.I. Novikov: Hot Shortness of Non-Ferrous Metals and Alloys (Nauka, Moscow, 1966) (in Russian).

[9] D.G. Eskin, Suyitno, L. Katgerman: Progr. Mater. Sci. Vol. 49 (2004), p.629.

[10] D.G. Eskin, Suyitno, J.F. Mooney, L. Katgerman: Metall. Mater. Trans. A Vol. 35A (2004), p.1325.

[11] V.S. Zolotorevskii, N.A. Belov: Physical Metallurgy of Foundry Aluminium Alloys (MISiS, Moscow, 2005) (in Russian).
