Ultra Rapid Softening of High Strength Structural Steels by Thermomechanical Treatment


Article Preview

This study aims to shorten the softening treatment period as possible in high strength structural steels. The steel used is SCM440 steel. As an initial microstructure, martensite, bainite, pearlite and complicated microstructure consisting of ultrafine polygonal, martensite and equiaxed cementite were extensively examined to understand their softening process on aging at 973K. These initial microstructures were prepared by heat or thermomechanical treatment. Their initial Vickers hardness (Hv(10kgf)) were 634, 281, 219 and 238, respectively. It is noteworthy that within five minutes on aging hardness of the complicated microstructure reached lower than Hv200, while it took more than several hours for other initial microstructures. A quantitative evaluation of microstructures appears to help in understanding the mechanism of the softening kinetics.



Materials Science Forum (Volumes 539-543)

Main Theme:

Edited by:

T. Chandra, K. Tsuzaki, M. Militzer , C. Ravindran




Y. Adachi and K. Tsuzaki, "Ultra Rapid Softening of High Strength Structural Steels by Thermomechanical Treatment", Materials Science Forum, Vols. 539-543, pp. 4807-4812, 2007

Online since:

March 2007




[1] Y.L. Tian and R.W. Kraft: Metall. Trans. A Vol. 18(1987), p.1403.

[2] K. Nakajima: 98th, 99th Nishiyama Memorial Lecture, ISIJ, (1984), p.57.

[3] Y. Kanetsuki, M. Katsumata and H. Sawada: Tetsu-to-Hagane Vol. 75(1989), p.1178.

[4] Y. Kanetsuki, M. Katsumata and T. Inoue: Tetsu-to-Hagane Vol. 76(1990), p.73.

[5] T. Kato and A. Yamamoto: CAM-ISIJ Vol. 6(2000), p.1241. Ostwald growth Dissolution of pearlite Dissolution of pearlite Matrix grain growth Matrix grain growth �� Enrichment of Cr, Mn, Mo Re-partitioning of Cr, Mn.
