Plasma Etching for the Application to Low-K Dielectrics Devices

Abstract:

Article Preview

We present a study of the photoresist (PR) etching and the low-k materials damage using a ferrite-core inductively coupled plasma (ICP) etcher, in order to develop an etching process for the low-k dielectric devices. We reveal that the N2/O2 flow ratio and bias power affected the PR etching rate. By Fourier transform infrared spectroscopy and HF dipping test, we investigated the effect of the gas flow ratio and bias power on the amount of etching damage to the low-k material.
