Thick Epilayer for Power Devices

Abstract:

Article Preview

Growth of thick epitaxial SiC layers needed for high power devices is presented for horizontal hot-wall CVD (HWCVD) reactors. We demonstrate thickness of epilayer of 100 μm and more with good morphology, low-doping with no doping variation through the whole thick layer and reasonable carrier lifetime which mainly depends on the substrate quality. Typical epidefects are described and their density can dramatically be reduced when choosing correctly the growth conditions as well as the polishing of the surface prior to the growth. The control of the doping and thickness uniformities as well as the run-to-run reproducibility is also presented. Various characterization techniques such as optical microscopy, AFM, reflectance, CV, PL and minority carrier lifetime have been used. Results of high-voltage SiC Schottky power devices are presented.

Info:

Periodical:

Materials Science Forum (Volumes 556-557)

Edited by:

N. Wright, C.M. Johnson, K. Vassilevski, I. Nikitina and A. Horsfall

Pages:

47-52

Citation:

A. Henry et al., "Thick Epilayer for Power Devices", Materials Science Forum, Vols. 556-557, pp. 47-52, 2007

Online since:

September 2007
