Fabrication of FBG Strain Gauge Used for High Temperature Strain Monitoring

Abstract:

Fiber Bragg Grating (FBG) sensing technology is widely used in detection of temperature, strain and etc. Now the application of FBG sensor is limited below 200°C. Application over 200°C is still an engineering challenge since no suitable FBG strain gauge. In this paper, FBG strain gauge structure which consists of three FBGs is designed and fabricated based on the theoretical strain and stress analysis. This strain gauge can be used for the real-time high temperature strain monitoring situation. The elastic high-temperature alloy (10MoWVNb) is chosen as the substrate. The three FBGs with a similar performance are fabricated on the substrate by high-temperature glue. Among the three FBGs, FBG1 is used for the horizontal strain monitoring, FBG2 is used for the longitudinal strain monitoring, and FGB3 is used for high temperature cross-sensitive compensation. The fabricated high temperature FBG gauge is demonstrated suitable for high temperature strain monitoring by experiment.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 920-923
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.920
• Online since: October 2014
• Authors: Shao Jun Zhang, Yue Ming Liu
• Keywords: Fabrication Process, FBG, High Temperature, Strain Monitoring

References

[1] Zhan Yage, Xiang Shiqing, et al. Progress in applications and developing prospect of in-fiber Bragg grating sensors [J]. Physics, 2004, 33(1): 59~61.

[2] Pang Dandan, Sui Qingmei, Jiang Minshun. A new high temperature resistant FBG sensing system[J]. Journal of Optoelectronics·Laser, 2011, 22(10): 1459~1462.

[3] Yage Zhan, Hua Wu, et al. Fiber grating sensors for high-temperature measurement [J]. Optics and Lasers in Engineering , 2008, 46: 349~354.

DOI: 10.1016/j.optlaseng.2007.10.008

[4] Yang Ruipeng, Qi Dong, Jiang Daosheng, et al. Experimental Stress Analysis and strain Measurement in high Temperature conditions [J]. Chemical Engineering and Machinery, 2005, 32(6): 346~349.

[5] Zhou Xuejun, Ma Xiao, et al. Efficiency analysis of strain monitoring temperature of FBG sensors[J]. Journal of Shandong Jian zhu university, 2010, 25(4): 386~390.

[6] Liu Bo, Niu Wencheng, YANG Yifei, et al. A novel fiber Bragg grating accelerometer [ J] . Chinese Journal of Scientific Instrument, 2006, 27( 1) : 42~44.

[7] Liu Wenqian, Ma Yaoyuan, et al. Non-Gel Encapsulation Process of a High Temperature Strain Fiber Bragg Grating Sensor and Its Sensing Properties [J]. Chinese journal of sensors and actuators, 2013, 26(7): 927~931.

[8] Peng Baojin, Liao Yanbiao, et al. New Method of measuring fibers' valid elastic optic constant [J]. Optical Technique, 2005, 31(5): 655~658.
