Research on Axial Magnetic Force and Rotor Mechanical Stress of an Air-Cored Axial-Flux Permanent Magnet Machine Based on 3D FEM

Abstract:

Due to its compact construction and high power density, the axial-flux permanent-magnet (AFPM) machine with coreless stator has obtained more and more attention and interest from researchers. For an AFPM machine with coreless stator, the axial magnetic attraction force may cause the rotors’ deflection and affect the machine’s reliability. In this paper, the magnetic field and the rotor mechanical strength of a coreless stator AFPM machine are studied. Finite-element method and analytic method are both used to calculate the axial attraction magnetic force between the two rotor discs. Structure finite-element analysis is used to simulate the maximum stress and deflection due to the axial magnetic force. The research is very significant to the power density elevation of the AFPM machine.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 160-163
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.160
• Online since: September 2011
• Authors: Yong Juan Cao, Yun Kai Huang, Long Jin
• Keywords: Axial Magnetic Force, Axial-Flux Permanent-Magnet (AFPM), Coreless Stator, Stress Analysis

References

[1] J. F. Eastham, F. Profumo, A. Tencono, R. Hill-Cottingham, P. Coles. and G. Gianolio: Novel axial flux machine for aircraft drive: Design and modeling: IEEE trans. on magnetics, Vol. 38 (2002) No.5, p.3003.

DOI: 10.1109/tmag.2002.803186

[2] T. F. Chan et al.: An axial-flux permanent-magnet synchronous generator for a direct-coupled wind-turbine system: IEEE trans. on energy conversion, Vol. 22 (2007) No.1, p.86.

DOI: 10.1109/tec.2006.889546

[3] M. Aydin, S. Huang and T. A. Lipo: Torque quality and comparison of internal and external rotor axial flux surface-magnet disc machines: IEEE transactions on industrial electronics, Vol. 53 (2006), No.3, p.822.

DOI: 10.1109/tie.2006.874268

[4] J. F. Gieras, R. J. Wang and M. J. Kamper: Axial Fulx Permanent Magnet Brushless Machines (Springer Science + Business Media B.V., Norwell 2008) p.153.

DOI: 10.1007/978-1-4020-8227-6

[5] S. Javadi and M. Mirsalim: A coreless axial-flux permanent-magnet generator for automotive applications: IEEE transactions on magnetics, Vol. 44 (2008), No.12, p.4591.

DOI: 10.1109/tmag.2008.2004333

[6] N. F. Lombard and M. J. Kamper: Analysis and performance of an ironless stator axial flux PM machine: IEEE transactions on energy conversion, Vol. 14 (1999), No.4, p.1051.

DOI: 10.1109/60.815027

[7] Renyuan Tang: The Theory and Design of Modern Permanent Magnet Motor (Machine Industry Publishing Company, Beijing 1997) p.308. (In Chinese)
