Research on Strain of Structure about Leg of Cantilever Side Material Piling Machine Based on ANSYS

Abstract:

With a experiment calculation example, this paper presents the dynamic simulation method based on virtual prototype according to the cantilever material piling machine with the stress of the big leg problems. first We established virtual prototype of the side cantilever material piling machine pig leg and analyzed the stress of the incoming car pig leg in three different work conditions , it is concluded that the stress and strain distribution. Combine the date of dynamic strain and static train in field surveys, by comparing the data, we can think finite element model is correct, and work on the model of stress and strain problem, and propose the reasonable design improvement. The result provides reliable date for improving and optimizing of the Big-Leg of Cantilever Side Material Piling Machine.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1793-1796
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1793
• Online since: September 2011
• Authors: Qiang Cui
• Keywords: Finite Element Analysis (FEA), Material Piling Machine, Optimization Design, Stress

References

[1] K.W. Ma and Z.H. Yang: Material Handling & Separation Technology, p.7 (in Chinese).

[2] M.D Wang: Mining & Processing Equipment, Vol.33, (2005), p.133 (in Chinese).

[3] Y. LI: Journal of Qingdao Agricultural University (Natural Science). (2009), No.26, p.46 (in Chinese).

[4] M. Yang: Harbin Railway Science & Technology. (2004), p.13(in Chinese).

[5] Y.J. Xue and H. Li: Port Technology. (2006), No.9, p.36(in Chinese).
