Research on Fast Locating Solder Joint on Fully-Automatic LED Wire Bonder

Abstract:

A new method is put forward to positioning solder joints on fully-automatic LED wire bonder. In the method, the image of a LED micro-chip is first processed with GPU by median filtering based on average and adaptive window size. Then the potential areas of the micro-chip are determined by the algorithm of adaptive threshold for image. These potential areas are stored in groups according to distances. The best potential area of each group is screened out in terms of symmetrical features of grey scale after that it is a weighted process. Finally, the LED micro-chip solder joint is precisely located by calculating the center of mass. The results show that the proposed method is fast, accurate, effective, suitable for automation, and has no requirement to the consistency of the shape of LED micro-chips.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1827-1830
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1827
• Online since: September 2011
• Authors: Zhi Chao Huang, Mu Liu, Hua Dong Liu, Xing Ming Fan, Yi Zhong
• Keywords: Center of Mass, Fully-Automatic LED Wire Bonder, Graphic Processing Unit (GPU), LED Micro-Chip, Location

References

[1] George F. Blackwell Machine Vision in the Tire Industry, IEEE, Vol. 069. (1989) p.67.

[2] Gary Bradski and Adrian Kaebler Learning OpenCV(Second Edition) (Tsinghua University Press China 2009).

[3] Carsten Steger and Markus Ulrich Machine vision algorithms and Applications(Bilingual edition)(Tsinghua University Press China 2008).

[4] Xin Wang Multiscale Median Filter for Image Denoising, IEEE Vol. 10. (2010) No. 1, p.67.

[5] Jason Sanders and Edward Kandrot CUDA Sample analysis(Second Edition) (Tsinghua University Press China 2010).
