Dynamic Responses of the Powerhouse Structure of Hydropower Stations due to Hydraulic Excitation

Abstract:

As the capacity and water head of large hydropower projects become higher and higher, the flow-induced structural vibration of powerhouse becomes a very important problem for the design and operation process. Especially as the water head and the running speed are much higher for the pump-turbine than the general turbine, the hydraulic exciting vibration is very remarkable. In this paper the simulation results of free-vibration characteristics of powerhouse structure for different types were concluded and the frequency behavior of the pressure fluctuation in spiral case and draft tube were discussed. The structural dynamic responses under hydraulic exciting were presented including the dynamic responses of displacement, velocity, acceleration and stresses. Based on the vibration criterion of the powerhouse structure, the vibration evaluation was made.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 233-237
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.233
• Online since: September 2011
• Authors: Jing Chen, Zhen Yue Ma, Yun Liang Zhang
• Keywords: Dynamic Response, Hydraulic Exciting, Hydropower Project, Powerhouse

References

[1] H. Ohashi: Vibration and oscillation of hydraulic machinery (Avebury Technical, England 1991).

[2] Z.Y. Ma and Y.X. Dong: Dynamics of water turbine generator set (Dalian University of Technology Press, China 2003). (In Chinese)

[3] Z.Y. Ma and Y.X. Dong: Vibration and its corrective actions of water turbine generator set and power house (China Water Power Press, China 2004). (In Chinese)

[4] Z.Y. Ma, C.N. Shen, Y.B. Wang, et al: Journal of Hydroelectric Engineering, Vol. 21 (2002) No.1, p.28. (In Chinese)

[5] P.J. Tang: Hongshui River, Vol. 19 (2000) No.3, p.59. (In Chinese)

[6] H. Wen, C.S. Zhang, Y.Z. Liu, Y.W. Zhu and B.D. Gu: Water Power, Vol. 24 (1998) No.8, p.28. (In Chinese)

[7] J.J. Lian, L. Qin and C.L. He: Journal of Tianjin University, Vol. 39 (2006) No.2, p.176. (In Chinese)

[8] J. Chen, Z.Y. Ma, Z.M. Liu, H.B. Xie and S.W. Du: Journal of Hydroelectric Engineering, Vol. 23 (2004) No.5, p.36. (In Chinese)

[9] J.H. Ouyang, H.Q. Chen and D.Y. Li: Journal of Hydraulic Engineering, Vol. 36 (2005) No.4, p.484. (In Chinese)

[10] K. Shen, Z.Q. Zhang and Z. Liang: Water Resources and Power, Vol. 21 (2003) No.1, p.73. (In Chinese)
