Study on Dynamic Simulation of 4-Bundle Ice-Coated Conductor Galloping Based on 3-D Model

Abstract:

Galloping of power transmission lines is a low frequency self-oscillation with large amplitude. The aerodynamic effect on each sub-conductor of 4-bundle conductor is different due to wake-flow-influence. In order to explore the reasons leading to galloping, a 3-D model for power transmission line is built. A two-node quadratic beam element in 3-D and a structure mass element are applied to establish the finite element model of iced 4-bundle conductor in ANSYS software. Then dynamic transient response calculations are made on this model. According to the results, difference in vibration of sub-conductors and frequency coupling of torsional and transverse vibration can be confirmed. The simulation results illustrate the wake-flow-influence effect and the coupled motions effect on galloping of 4-bundle conductor.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 474-477
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.474
• Online since: September 2011
• Authors: Shi Jing Wu, Zeng Lei Zhang, Zhen Hao Liu, Ji Cai Hu
• Keywords: 3D Model, 4-Bundle Conductor, Dynamic Simulation, Galloping

References

[1] Y.L. Guo, G.X Li and C.Y. You: Galloping of Power Transmission Line (Electric Power Press, China 2002). (In Chinese)

[2] D.W. Shi: Mechanical Kinetics (Power Press, China 2006).(In Chinese)

[3] B. Yan, J. Hu and H.Y. Zhang: Journal of Vibration Engineering, Vol.23 (2010).No.3, p.311. (In Chinese)

[4] S.J. Wu, Z.H. Liu and X.S. Wang: 3rd International Conference on Mechanical Engineering and Mechanics (Beijing, China, October 21-23, 2009). Vol. 1, p.1073.

[5] L.F. Shen, S.J. Wu and X.S. Wang: Electric Power Construction, Vol.31 (2010).No.11, p.34. (In Chinese)

[6] L.M. Xi: Journal of Tianjin Institute of Urban Construction, Vol.10 (2004).No.3, p.156. (In Chinese)
