Numerical Simulation on the Torsion Behavior of '+'-Shaped Columns under the Actions of Pressure and Torque

Abstract:

Nonlinear finite element analysis (FEA) for the torsion behavior of reinforced concrete '+'-shaped columns with various axial load ratios was carried out by the general software ANSYS. Then a comparison between the FEA calculations and the test results is made. The numerical examples show that: (1) the cracking torque and ultimate torque of reinforced concrete '+'-shaped columns under the combined actions of axial force and torque can be predicted with a reasonable accuracy. (2) the axial ratio has significant effects on the torsion behavior '+'-shaped columns. The cracking torque and ultimate torque of '+'-shaped columns increase with an increase of axial load ratio. Comparing with reinforced concrete '+'-shaped column with an axial load ratio of 0.063, the cracking torque and ultimate torque of reinforced concrete '+'-shaped columns with axial load ratios of 0.189 and 0.314 were increased by 28.3% and 71.9%, 79.4% and 96.0%, respectively.

You might also be interested in these eBooks

Vibration, Structural Engineering and Measurement I

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 105-107)

Pages:

796-799

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.105-107.796

Citation:

Cite this paper

Online since:

September 2011

Authors:

Dan Li, Yu Ye Xu, Zheng He Qiu, Yong Lin Zheng

Keywords:

‘+’-Shaped Cross Section, Column, Numerical Simulation, Reinforced Concrete (RC), Torsion Behavior

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. Wang, C.K. Huang, M. Liu and Z.W. Gao: J. Build. Struct., Vol. 22 (2001) No. 5, p.37. (In Chinese)

Google Scholar

[2] D. Wang, C.K. Huang and M. Liu: China Civ. Eng. J., Vol. 38 (2005) No. 7, p.34. (In Chinese)

Google Scholar

[3] W.L. Cao, G.Z. Hu, E.J. Wu and M.J. Zhou: Earthq. Eng. Eng. Vib., Vol. 19 (1999) No. 3, p.54. (In Chinese)

Google Scholar

[4] Y.Y. Xu and B. Wu: Fire Saf. J., Vol. 44 (2009) No. 6, p.869.

Google Scholar

[5] Z.H. Qiu: Study on the Torsional Behavior of Reinforced Concrete Special-Shaped Columns under the Actions of Pressure and Torque (MS., Huaqiao University, China 2011), p.7.

Google Scholar

[6] X.Z. Lu and J.J. Jiang: Build. Struct., Vol. 41 (2003) No. 6, p.7. (In Chinese)

Google Scholar

[7] Z.H. Guo: Principles of Reinforced Concrete (Tsinghua University Press, China 2003), p.65.

Google Scholar

[8] Ministry of Construction of P. R. of China: Code for Design of Concrete Structures (China Architecture & Building Press, China 2002), p.179.

Google Scholar
