Study on Relationship between Partial Load and Rib Effect Coefficient of Refrigeration Heat Exchanger Used in Air Conditioning

Abstract:

The relationship between thermal resistance ratio ζ(the ratio of thermal resistance between two sides of the tube wall) and load rate, according to heat transfer theory, is derived from simplifying the heat transfer model of heat exchanger. Considering the different running time of heat exchanger under variable load, the operation heat is proposed. Then the range of thermal resistance ratio for evaporator and condenser is determined and the law of thermal resistance is validated by analyzing the example. As a result, the relationship between rib effect coefficient and the thermal resistance ratio is established. Furthermore, value analysis of rib effect coefficient is analyzed. Results of this study show that the heat transfer performance of evaporator and condenser maximizes when ζ=1 at the partial load rate of (0.25, 0.50). Meanwhile, rib effect coefficient on the water side is less than that of the refrigerant side for evaporator and condenser.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 2922-2930
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.2922
• Online since: October 2011
• Authors: Hou Hua Wang, Hou Shuai Wang
• Keywords: Condenser, Evaporator, Operation Heat, Rib Effect Coefficient, Thermal Resistance Ratio

References

[1] Mouxiong Zhang: Heating Ventilating & Air Conditoning Vol. 30(2000), pp.56-57, in Chinese.

[2] XinYi, Xianying Liu: Journal of Chongqing University Vol. 25(2002), pp.100-103, in Chinese.

[3] Zonghu Lin, Jun Wang, Ruiyang Li et. al: Heat Transfer Enhancement(Chemical Industry Press, Beijing 2007), in Chinese.

[4] Songwen Qian, Dongsheng Zhu, Qingling Li et. al: Heat Transfer Enhancement of Tubular Type Heat Exchanger(Chemical Industry Press, Beijing2003), in Chinese.

[5] Quansheng Zeng: Chemical Engineering Design Vol. 1(1998), pp.26-27, in Chinese.

[6] Qisen Yan: Refrigeration Technology Used in Air Conditioning(China Architecture & Building Press, 4th Edn, Beijing2010), in Chinese.

[7] S.W. Wang and J. Burnett: Applied Thermal Engineering Vol. 21(2001), pp.1083-1103.

[8] T. N. Aynur: Energy Building Vol. 42(2010), pp.1106-1112.

[9] Ximin Zhang and Zepei Ren: Heat Transfer(China Architecture & Building Press, 4th Edn. Beijing 2001), in Chinese.

[10] T. C. Carnavos: Heat Transfer Engineering Vol. 4(1980), pp.32-37.

[11] Y.S. Zhou: Journal of Refrigeration Vol. 4(1999), pp.29-32.

[12] W. Kirsner: ASHRAE Journal Vol. 40(1998), pp.37-42.

[13] R.K. Shah and D.P. Sekulic': Fundamentals of Heat Exchanger Design(Wiley, Hoboken, New Jersey2003).

[14] Guangming Cheng and Chaohan Zhang: Refrigeration and Low-temperature Equipment (Zhejiang University Press, Zhejiang2003), in Chinese.
