Contact Pressure Research of Drill Pipe and Packer of Rotating Blowout Preventer

Abstract:

The contact pressure of packer of rotary blowout preventer (BOP) act on drill pipe is closely related to the life and performance of rubber core. According to the actual working condition of the drill pipe and connector passing through the packer in the process of drilling, this paper establishes a three-dimensional mechanics model for sealed drill pipe of packer with ABAQUS finite element software , it simulates the characteristics of contact pressure changing while the drill pipe and drill pipe joints went through the hole of the packer, and obtained the location and the distribution rule of the maximum contact pressure of drill pipe packer at a certain wellhead pressure, and also studied the different packer materials and movement characteristics of drill pipe, and mastered the influence disciplinarian of the friction coefficient between the packer and drill pipe that act for the packer’s contact pressure.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 3200-3204
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.3200
• Online since: October 2011
• Authors: Bin Li, Si Mao Zhang
• Keywords: Contact Pressure, Drill Pipe, Finite Element Analysis (FEA), Packer, Rotating Blowout Preventer

References

[1] Zhang Hui1, Liu Chunquan and Luo Haiyu, Design of a Rotating Blow-out Preventer(RBOP) with a New Sealing Structure, China Mechanical Science and Technology for Aerospace Engineering, 2009, 28（2）: 234-237.

[2] Hocine Bechiar et al. Strain energy density function for carbon black filled rubber vulcanized for industrial applications. Mecanique　&　Industries, 2002, 3：245～252.

[3] ZHANG Hui, LIU Chun-qua and AI Zhi-jiu, The Review of the Situation and the Developing Trend of Rotary Blowout Preventer , China Oil Field Equipment, 2007, 36（1）: 28-32.

[4] Hocine Bechiar et al. Strain energy density function for carbon black filled rubber vulcanized for industrial applications[J]. Mecanique & Industries, 2002, 3：245~252.

[5] YE Zhe-Wei and LIANG Zheng, The Failure Analysis and Improvement of a Type of Rotating BOP Development & Innovation , China Machinery & Electrical Products, 2010, 23（4）: 40-42.

[6] FEI Gen-sheng, LI Bin and YANG Chun-lei, et al. Finite element analysis and optimal design of rotating blowout preventer, China Machinery Design & Manufacture, 2008, 5: 16-1.
