Thermal Effect on Buckling of General Dome Ends Using Finite Element Method

Abstract:

In this study, the elastic buckling behavior of general dome ends under presumed temperature distribution and external pressure was studied. The Finite Element Method (FEM) was used to predict the elastic buckling pressure behavior when the domes were subjected to various operating temperatures. The freedom of the edges of the dome ends was completely restricted to simulate clamped end conditions. The four-centered ellipse method was used to construct the geometry of the dome ends. The influence of geometrical parameters such as thickness, knuckle radius, and the ratio of minor axis to the major axis of dome ends and the effect of temperature on critical buckling pressure of hemispherical, ellipsoidal, and torispherical dome ends were studied. It has been found that the under thermal condition, the thickness and the shape of the domes have the most significant effect on the critical buckling pressure. Two models of torispherical and ellipsoidal dome ends are analyzed by using finite element analysis.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 340-345
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.340
• Online since: October 2011
• Authors: Behzad Abdi, Hamid Mozafari, Ayob Amran, Roya Kohandel
• Keywords: Buckling Pressure, Ellipsoidal, External Pressure, Finite Element Method (FEM), Four-Centered Ellipse Method, Hemispherical, Torispherical

References

[1] B. Abdi, , H. Mozafari, A. Ayob, Buckling behavior of general dome ends under external pressure using finite element analysis, Key Engineering Materials, 471-472, ( 2011), pp, 833-838.

DOI: 10.4028/www.scientific.net/kem.471-472.833

[2] P. Jasion, K. Magnucki, Elastic Buckling of barreled shell under external pressure, Thin-Walled Structures, 45, ( 2007), pp, 393-399.

DOI: 10.1016/j.tws.2007.04.001

[3] D. Mackenzie, D. Camilleri, R. Hamilton, , Design by analysis of ductile failure and buckling in torispherical pressure vessel heads, Thin-Walled Structures, 46, (2008), pp, 963-974.

DOI: 10.1016/j.tws.2008.01.033

[4] T. Hong, , J.G. Teng, Imperfection sensitivity and postbuckling analysis of elastic shell of revolution, Thin-Walled Structures, 46, (2008), pp, 1338-1350.

DOI: 10.1016/j.tws.2008.04.001

[5] B. Yu, L.F. Yang, Elastic modulus reduction method for limit analysis considering initial constant and proportional loading, Finite Element in Analysis and Design, 46, (2010), pp.1086-1092.

DOI: 10.1016/j.finel.2010.07.016

[6] A. Abdullah, S.M. Bedan, A.K. Ariffin, and M.M. Rahman, Fatigue Life Assessment for Metallic Structure: A Case Study of Shell Structure under Variable Amplitude Loading, Journal of Applied Sciences, 8, (2008), pp.1622-1631.

DOI: 10.3923/jas.2008.1622.1631

[7] Al-Qablan, Semi-analytical Buckling Analysis of Stiffened Sandwich Plates, Journal of Applied Sciences, 10, (2010), pp.2978-2988.

DOI: 10.3923/jas.2010.2978.2988

[8] N. Boumechra, D.E. Kerdal, The P-version Finite Element Method Using Bezier-Bernstein Functions for Frames, Shells and Solids, Journal of Applied Sciences, 6, (2006), pp.2334-2357.

DOI: 10.3923/jas.2006.2334.2357

[9] E.A. Thornton, Thermal buckling of plates and shells,. Applied Mech. Rev, 46 (1993): 485-506.

[10] M. Amabili, Shell-plate interaction in the free vibrations of circular cylindrical tanks partially filled with a liquid,: The artificial spring method. J. Sound Vibration, 199: (1997), 431–452.

DOI: 10.1006/jsvi.1996.0650

[11] J. Kochupillai, , N. Ganesan and C. Padmanabhan, A semi-analytical coupled finite element formulation for shells conveying fluids, Comput. Structures, 80: (2002), 271–286.

DOI: 10.1016/s0045-7949(02)00008-1

[12] J.G. Teng, Buckling of thin shells: Recent advances and trends,. Applied Mech. Re., 49: (1996), 263–274.

DOI: 10.1115/1.3101927

[13] J. Mackerle, Review finite elements in the analysis of pressure vessels and piping, an addendum: A bibliography (2001-2004),. Int. J. Pressure Vessels Piping, 82, (2005), 571-592.

DOI: 10.1016/j.ijpvp.2004.12.004

[14] M.F. Yang, C.C. Liang and C.H. Chen, A rotational shape design of externally pressurized torispherical dome ends under buckling constraints,. Comput. Structures, 43: (1992), 839-851.

DOI: 10.1016/0045-7949(92)90298-e

[15] B. Abdi, H. Mozafari, A. Ayob, Using Imperialist Competitive Algorithm to Find the Optimum Shape Design of Internally Pressurized Torispherical Dome Ends Based on Buckling Pressure, International Journal of Engineering, (IJE), Volume (4): Issue (5), (2010).

DOI: 10.4028/www.scientific.net/amm.110-116.956
