Electric Heating Power Optimization of Natural Gas Pipeline

Abstract:

After the analysis of gas flow, energy consumption is mainly in the process of heating gas pipeline and natural gas throttle. For this problem, this paper, heat transfer, thermodynamics, computational fluid dynamics are used, the pipeline throttling, convection of natural gas in the pipe and the heat transfer between the gas, wall panels, heating cable, insulation, soil and the atmosphere are all considered, thermal analysis model between the wellhead and the gas gathering station is established, the electric heating power on the gas pipeline is optimized, the optimal electric heating power can be calculated when the temperature of wellhead and gas gathering station is expected to reach are known. The effect of tube diameter, gas volume, surface temperature on the heating power is analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 135-136)
• Pages: 516-521
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.135-136.516
• Online since: October 2011
• Authors: Chun Liang Zhang
• Keywords: Electric Heating, Gas Pipeline, Natural Gas, Power Optimization

References

[1] SCHORRE C E. How To Calculate Flow Temperature in a Gas Pipeline [J]. Oil & Gas Journal, 1954, 9(27): 66~68

[2] Wu Ming, Chen Qingyong, Chen Baodong. The discussion of optimal economic thickness of tubing the insulation in the heat transfer [J]. Gas Storage and Transportation, 1993,12(2):46~52

[3] Liu Chunyang. Electric heating principle and general usage [J]. China Offshore Oil and Gas (Engineering) ,1998,10(6):14~17

[4] Shi Weiling. The application of electric heating technology in the pipeline [J]. Petroleum Chemical Industry,2000,4：82~83

[5] Li Changjun. Natural gas pipeline [M]. Petroleum Industry Press, 2000：1~15, 23~27, 29~37, 47~50, 62,86~94
