Target Recognition Using Infrared Polarization Imaging System

Abstract:

In this paper, we developed an infrared polarization imaging system. The system is composed of imaging lens, IR polarizing filter, medium wave IR detector, and image acquisition system. The design scheme of implementing target recognition with IR polarization imaging system was presented, and the IR Images with polarization information have been acquired by this system. On the basis of Stokes parameters and polarization IR images processing, the images of linear Stokes parameters (I, Q, U), the image of degree of linear polarization (P image) and the image of angle of polarization (X image) could been obtained. The image of PUX fusion image could be achieved by the pseudo color fusion. The results of actual experiment and quantitative analysis data confirm that the target in the processed images obtained from IR polarization imaging system is much clear than that in the original IR image.

• Periodical: Applied Mechanics and Materials (Volumes 135-136)
• Pages: 983-988
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.135-136.983
• Online since: October 2011
• Authors: Na Ding, Jiao Bo Gao, Jun Wang
• Keywords: Fusion Image, Infrared Polarization Imaging, Stokes Parameters, Target Recognition

References

[1] J. Craven-Jones, M. W. Kudenov, M. G. Stapelbroek, and E. L. Dereniak, Infrared hyperspectral imaging polarimeter using birefringent prisms, Applied Optics, 50 (2011) 1170-1185.

DOI: 10.1364/ao.50.001170

[2] I. Ulusoy and H. Yuruk, New method for the fusion of complementary information from infrared and visual images for object detection, IET Image Processing, 5 (2011) 36-48.

DOI: 10.1049/iet-ipr.2009.0374

[3] J. Shaik and K. M. Iftekharuddin, Detection and tracking of targets in infrared images using Bayesian techniques, Optics and Laser Technology, 41 (2009) 832-842.

DOI: 10.1016/j.optlastec.2008.11.007

[4] CHENG Gang, ZHU Hui, ZHANG Yong, et al., Adaptive algorithm for small target detection in infrared searching system, Journal of Applied Optics, 31 (2010) 128-131.

[5] J. P. Houston, S. Ke, W. Wang, C. Li, and E. M. Sevick-Muraca, Quality analysis of in vivo near-infrared fluorescence and conventional gamma images acquired using a dual-labeled tumor-targeting probe, Journal of Biomedical Optics, 10. (2005).

DOI: 10.1117/1.2114748

[6] C. Vogel, E. Wessel, and H. W. Siesler, Fourier transform infrared spectroscopic imaging of anisotropic poly(vinylidene fluoride) films with polarized radiation, Applied Spectroscopy, 62 (2008) 599-603.

DOI: 10.1366/000370208784658039

[7] D. A. Lavigne, M. Breton, G. Fournier, M. Pichette, and V. Rivet, A New passive polarimetric imaging system collecting polarization signatures in the visible and infrared bands, Orlando, FL, United states, (2009).

DOI: 10.1117/12.819011

[8] K. H. Mller and I. Trabjerg, Investigation of problems associated with infrared image detection using rotating polarizers, Infrared Physics and Technology, 46 (2005) 351-354.

DOI: 10.1016/j.infrared.2004.06.005

[9] K. N. Liou, S. C. Ou, Y. Takano, and Q. Liu, A polarized delta-four-stream approximation for infrared and microwave radiative transfer: Part I, Journal of the Atmospheric Sciences, 62, (2005). 2542-2554.

DOI: 10.1175/jas3476.1

[10] F. A. Sadjadi, Invariants of passive infrared polarization transformations, New York, NY, United states, (2006).
