The Direct Torque Control Research of Permanent Magnet Linear Synchronous Motor

Abstract:

In order to improve the dynamic servo performance of PMLSM, a classical direct torque control (DTC) scheme based on bang-bang control is proposed in the paper. The proposed control method uses the bang-bang hysteresis controller formed a dual-closed loop control system, it contains torque loop and flux loop. The DTC control model was established and the simulation experiment was made. The simulation experiment results show that the DTC can improve the dynamic performance of PMLSM. It can reduce the ripples of speed and torque, so that it can provide more precision and accuracy servo performance.

• Periodical: Applied Mechanics and Materials (Volumes 143-144)
• Pages: 350-354
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.143-144.350
• Online since: December 2011
• Authors: Jun Zhu, Xu Dong Wang, Bao Yu Xu, Hai Chao Feng
• Keywords: Bang-Bang Control, Direct Torque Control (DTC), PMLSM, αβ Static Coordinate

References

[1] Zhang Yu: Research of Direct Torque Control in permanent Magnet Synchronous Motor Drives. Master Dissertation for Hefei University of Technology, (2007).

[2] Zhang Zhijing, Liu Chengying: Compensation Methods of Longitudinal End Effects in Permanent-magnet Linear Synchronous Motor. Proceedings of the CSEE, Vol. 30 (36) (2010) p.46–52.

DOI: 10.1109/mace.2010.5535740

[3] Wang Chenyuan, Xia Jiakuan, Sun Yibiao: Modern Control Technique of Electric Machines, edit by China Machine Press, Beijing (2010) , in press.

[4] Yu Rui, You Linru, Mao Zongyuan: Direct Torque Control System and Simulation of Permanent Magnet Synchronous Motor. Microcomputer Information, Vol. 4 (2006) pp.69-71.

[5] Yao Hailan , Xu Guoqin , Yuan Dengke: The New Space Voltage Control of the Direct Torque Control of Permanent Magnet Synchronous Motors. Mechatronics, Vol. 2 (2008) pp.65-68.
