RV Reducer Backlash Analysis Based on Robust Design

Abstract:

The RV reducer backlash is well controlled by means of robust design. Some factors influencing backlash are analyzed and divided into controllable factors and uncontrollable (noise) factors. The requirements for experimental factors are met for robust design. The experiment analysis is proposed by using orthogonal experiment and G.Taguchi robust design for each of effecting backlash factors. The optimum parameters are obtained for maximum signal noise ratio (SNR). The contribution rate for each factor influencing backlash is presented. Finally, RV reducer’s backlash is well decreased and achieved ideal result.

• Periodical: Applied Mechanics and Materials (Volumes 148-149)
• Pages: 418-421
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.148-149.418
• Online since: December 2011
• Authors: Yong Hua Li, Wei Li, Wei Dong He
• Keywords: Backlash, G.Taguchi Method, Orthogonal Experiment, SNR

References

[1] L. X. Li, W. D. He and X. Q. Wang: Journal of Dalian Railway Institute. Vol. 20 (1999), p.1.

[2] Y. K. Wu, J. Y Zheng, T. Q. Chen and W. D. He: Journal of Dalian Railway Institute . Vol. 20(1999), p.28.

[3] T. N. Goli: Quality and Reliability Engineering. Vol. 9(1993), p.185.

[4] K. N. Otto: Journal of Mechanical Design. Vol. 115(1993), p.5.

[5] Z. J. Han: Three Stage Design (China Machine Press, Beijing 1992).

[6] L. Z. Chen: Robust Design (China Machine Press, Beijing 2000).

[7] K. Jami, R. C. Byung and A. Jiju: Int. J. Adv. Manuf. Technol. Vol. 35(2008), p.1100.

[8] S. Wimalin and T. James: Neural Computing and Applications. Vol. 14(2005), p.337.
