Integrated Powertrain Control for Gear Shifting

Abstract:

Drivability and fuel economy are continuously emphasized during the development of automobiles, and shift quality is the most important part of the drivability. To improve the shift quality, the integrated powertrain control strategy for gear shifting is presented in this paper. First of all, the transmission control strategy based on the turbine speed trajectory is proposed. Furthermore, an output torque observer is determined to implement the coordinated engine control, and then the torque based coordinated engine control is presented. Finally, the integrated powertrain control strategy is studied by experiments. The experimental results show that the integrated powertrain control reduces the shift jerk and the dissipated clutch energy during gear shifting.

• Periodical: Applied Mechanics and Materials (Volumes 148-149)
• Pages: 725-730
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.148-149.725
• Online since: December 2011
• Authors: Guo Qiang Wan, Ying Huang, Fu Jun Zhang, Gang Li
• Keywords: Automatic Transmission, Gear Shifting, Integrated Powertrain Control, Torque Based Control, Torque Observer

References

[1] Kondo T., Iwatsuki K., Taga Y, et al. Toyota 'ECT-I', a new automatic transmission with intelligent electronic control system. SAE paper, 900550, (1990).

DOI: 10.4271/900550

[2] Taniguchi H., Ando Y. Analysis of a new automatic transmission control sysytem for LEXUS LS400. SAE paper, 910639, (1991).

DOI: 10.4271/910639

[3] Narita Y. Improving automatic transmission shift quality by feedback control with a turbine speed sensor [C]. SAE Paper, 911938, (1991).

DOI: 10.4271/911938

[4] Hrovat D., Powers W.F. Computer control system for automotive powertrains [J]. IEEE control system magazine, 1988, 8 (4) : 3-10.

[5] Liu Z. Y, Gao J. W, Zheng Q. Robust clutch slip controller design for automatic transmission [C]. Proceeding of the institution of Mechanical Engineers, Part D: Journal of Automobile Engineering, 2011, 225: 1-17.

DOI: 10.1177/0954407011403661

[6] Gao B. Z, Chen H, Sanada K. Two degree of freedom controller design for clutch slip control of automatic transmission [C]. SAE Paper 2008-01-0537, (2008).

DOI: 10.4271/2008-01-0537

[7] Minowa T, Kimura H, Ishii J, et al. Smooth gear shift control system using estimated torque [C]. SAE Paper 941013, (1994).

DOI: 10.4271/941013

[8] Ibamoto M, Kuroiwa H, Minowa T, et al. Development of smooth shift control system with output torque estimation [C]. SAE Paper 950900, (1995).

DOI: 10.4271/950900

[9] Marciszko F. Torque sensor based powertrain control [D]. Daimler Chrysler AG, 2004: 24-30.

[10] Watechagit S, Srinivasan K. Implementation of on-line clutch pressure estimation for stepped automatic transmission [C]. American Control conference, 2005: 1607-1612.

DOI: 10.1109/acc.2005.1470197

[11] Green J. H, Hedrick J. H. Nonlinear speed control for automotive engines [C]. American Control Conference, 1990: 2891-2897.

DOI: 10.23919/acc.1990.4791247

[12] Huang Y., Zhao C. L, Zhang F. J., et al. An experimental study on the influence of integrated powertrain control on shifting quality [J]. Automotive Engineering, 2004, (6): 710-713.

[13] Gao J. W, Liu Z. Y. Integrated powertrain control of gearshift for automatic transmission [C]. 2010 First International Conference on Pervasive Computing, Signal Processing and Applications, 2010: 239-242.

DOI: 10.1109/pcspa.2010.65

[14] Wang Y. M. Research on tracked heavy-duty vehicle powertrain device integrated control [D]. Beijing: Beijing Institute of Technology, 2011: 97-102.
