Nonlinear Hysteretic Model of Giant Magnetostrictive Material Baesd on Inverse Magnetostritive Effect

Abstract:

In this paper, a kind of giant magnetostrictive material (GMM) model based on inverse magnetostritive effect was developed. Van de Pol nonlinear difference item was introduced to interpret the hysteresis phenomenon of the strain-magnetic field intensity (MFI) curve of GMM. The coupling relationship between strain and frequency was obtained in partial least-square regression method to describe the driftage phenomenon of the strain-MFI curves of GMM in different frequencies. Based on above, the final relationship among strain, MFI and frequency was set up. The result of significance test shows that the effects of all of the items in the final model are remarkable, and that of forecast test shows that the model can describe the characteristics of inverse magnetostritive effect of GMM in different frequencies well. The new GMM model is easy to be analyzed in theory, which is helpful to sensor design.

• Periodical: Applied Mechanics and Materials (Volumes 148-149)
• Pages: 785-788
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.148-149.785
• Online since: December 2011
• Authors: Xiao Qing Tang, Zhi Wen Zhu
• Keywords: Giant Magnetostrictive Material (GMM), Hysteretic Nonlinearity, Inverse Magnetostritive Effect, Partial Least-Square Regression

References

[1] D. C. Jiles, D. L. Atherton, Theory of ferromagnetic hysteresis, J. Mag. Mag. Mat. 61 (1986), 48-60.

[2] J. B. Restorff, H. T. Savage, A. E. Clark, Preisach modeling of hysteresis in Terfenol-D, J. App. Phy. 67 (1990) 5016-5018.

DOI: 10.1063/1.344708

[3] G. P. Carman, M. Mitrovic, Nonlinear constitutive relations for magnetostrictive materials with applications to 1-D problems, J. Int. Mat. Sys. Str. 6 (1995) 673-684.

[4] F. T. Calkins, R. C. Smith, A. B. Flatau, Energy-based Hysteresis Model for Magnetostrictive Transducers, IEEE Trans. Mag. 36 (2000) 429-439.

DOI: 10.1109/20.825804

[5] H. M. Zhou, Y. H. Zhou, X. J. Zheng, Numerical simulation of nonlinear dynamic responses of beams laminated with giant magnetostrictive actuators, Com. Mat. Con. 6 (2007) 201-211.

[6] L. Sun, X. J. Zheng, Numerical simulation on coupling behavior of Terfenol-D rods, Int. J. Sol. Str. 43 (2006) 1613-1623.

[7] R. G. Yan, B. W. Wang, Q. X. Yang, A numerical model of displacement for giant magnetostrictive actuator, IEEE Trans. App. Sup. 14 (2004) 1914-(1917).

DOI: 10.1109/tasc.2004.830929

[8] S. Chakraborty, G. R. Tomlinson, An initial experiment into the change in magnetic induction of a Terfenol-D rod due to external stress, Sma. Str. Mat. 12 (2003) 763-768.

DOI: 10.1088/0964-1726/12/5/013

[9] P. G. Evans, M. J. Dapino, Efficient magnetic hysteresis model for field and stress application in magnetostrictive Galfenol, J. App. Phy. 107 (2010) 299-307.

DOI: 10.1063/1.3318494

[10] T. Albach, A. Sutor, R. Lerch, Analysis of Magnetostrictive Microactuators, Tech. Mes. 12 (2003) 763-768.
