The Research of Drill Propulsion Mechanism with Eccentric Wheel Handspike Roller Movable Inner Gear Profile Curve Shaped-Connection

Abstract:

This paper deals with the existing propulsion mechanism, analyzes the disadvantages of the flat key and the spline, studies the features of the eccentric wheel handspike roller movable inner gear profile curve shaped-connection. In an existing chain propulsion mechanism, we change the fit of the inner hole of sprocket gear and the outer circle of intermediate shaft to get a eccentric wheel handspike roller movable inner gear profile curve shaped-connection (a keyless joint), then introduce the propulsion mechanism with eccentric wheel handspike roller movable inner gear profile curve shaped-connection. At last, we create the three-dimensional modeling of the propulsion mechanism, which would lay a solid foundation for the further study. This new propulsion mechanism has such advantages as self-centralizing, easy disassembly, low stress concentration, with a simple fit cross-section, transmitting big torque, suitable for the heavy loads of rock drilling.

• Periodical: Applied Mechanics and Materials (Volumes 152-154)
• Pages: 1397-1400
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.152-154.1397
• Online since: January 2012
• Authors: You Xin Luo, Heng Shu Li, Hui Jun Wen, Yu Zhou
• Keywords: Eccentric Wheel, Handspike Roller, Movable Inner Gear, Profile Curve, Propulsion Mechanism, Rock Drill, Shaped-Connection
