To Analyze the Effects of Geometric Misalignment in a Cylindrical Pressure Vessel

Abstract:

This particular work consider a pressurized vessel typically made of high strength low alloy steel and containing the geometric misalignment at the cylinder-to-cylinder junction. This misalignment produce in the vessel’s structure is because of girth weld that is evident in most of the fabrication of such type of structures apart from other factors which is beyond the scope of this study. This study evaluates the geometrical effects of mismatch on the structural integrity of the pressure vessel and prediction of stresses at the affected area of the cylinder. Analytical and Finite Element (FE) approaches are employed to analyze the configuration. FE analysis is performed by the use of ANSYS on one quarter of the structure due to symmetry. FE results are also compared with the analytical results of different authors. In addition, maximum allowable mismatch is also determined and is a part of this study.

• Periodical: Applied Mechanics and Materials (Volumes 152-154)
• Pages: 964-969
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.152-154.964
• Online since: January 2012
• Authors: Musharaf Abbas, Asif Israr, Atiq Ur Rehman
• Keywords: ANSYS, Finite Element Analysis (FEA), Misalignment, Peak Stress, Pressure Vessel Steel

References

[1] P. Buthod: Pressure Vessel Handbook, 10th Ed. (Pressure Vessel Publishing, Inc, Tulsa, OK, USA 1997).

[2] R.H. Johns: Theoretical Elastic Mismatch Stresses, Lewis Research Center, Cleveland, OHIO, USA (1966), NASA-TND-3254.

[3] D. R. Moss: Pressure Vessel Design Manual, Elsevier, USA (2004).

[4] R.H. Johns and T.W. Orange: Theoretical Elastic Stress Distribution Arising from Discontinuities and Edge Loads in several Shell type Structures (1961), NASA TR R- 103.

[5] T. B. Peter: Elastic Stresses at a Mismatched Circumferential Joint in a Pressurized Cylinder Including Thickness Changes and Meridional Load, Lewis Research Center, Cleveland, OHIO, USA, NASA (1966).

[6] W.C. Morgan and P.T. Bizon: Comparison of Experimental and Theoretical Stresses at a Mismatch in a Circumferential Joint in a Cylindrical Pressure Vessel (1966), NASA TN D-3608.

[7] R. Subhananda: Effect of Long-seam Mismatch on the Burst Pressure of Maraging Steel Rocket Motor Cases, Engineering Failure Analysis series (2004).

DOI: 10.1016/j.engfailanal.2004.01.004

[8] T. Aseer Brabin: Finite Element Analysis of Cylindrical Pressure Vessels having a Misalignment in a Circumferential Joint, International Journal of Pressure Vessels and Piping (2010).

DOI: 10.1016/j.ijpvp.2010.02.004

[9] S. Chattopadhyay: Pressure Vessel Design Practice (CRC Press 2005).

[10] D. Annaratone: Pressure Vessel Design (Springer-Verlag Berlin Heidelberg 2007).
