The Effect of an External AC or DC Electric Field on Collision and Agglomeration in an Electrostatic Agglomerator

Abstract:

This article simulated the collision and agglomeration between bipolarly charged particles in an electrostatic agglomerator. The EHD turbulent flow was solved and the flow parameters were extracted a priori. The particle initial charge was obtained by tracking particles with a certain diameter in the charging zone. When simulating collision and agglomeration in the agglomerating zone, the initial charge on a particle was sampled from the charge distribution by statistical analysis. The classical stochastic model for calculating collision between neutral particles was extended to calculate collision between charged particles, and the effect of particle charge on collision and agglomeration was embodied in the agglomeration criteria. The effect of an external DC and AC electric field on the collision and agglomeration was investigated.

• Periodical: Applied Mechanics and Materials (Volumes 152-154)
• Pages: 997-1005
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.152-154.997
• Online since: January 2012
• Authors: Xiang Rong Zhang, Lian Ze Wang
• Keywords: AC Electric Field, Agglomeration, Charge Distribution, Collision, DC Electric Field, EHD Flow, Gas-Solid Flow

References

[1] Ji, J. H., Hwang, J., Bae, G. N., and Kim, Y. G, Particle charging and agglomeration in DC and AC electric fields, J. Electrostat. 61 (2004) 57-68.

DOI: 10.1016/j.elstat.2003.12.003

[2] Xiang, X. D., Chen, B. Z., and Colbeck, I, Bipolar charged aerosol agglomeration and collection by a two-zone agglomerator, J. Environ. Sci-China. 13 (2001) 276-279.

[3] Hautanen, J., Kilpelainen, M., Kauppinen, E. I., Jokiniemi, J., and Lehtinen, K, Electrical agglomeration of aerosol particles in an alternating electric field, Aerosol Sci. Tech. 22 (1995) 181-189.

DOI: 10.1080/02786829408959739

[4] Soldati, A, On the effects of electrohydrodynamic flows and turbulence on aerosol transport and collection in wire-plate electrostatic precipitators, J. Aerosol Sci. 31 (2000) 293-305.

DOI: 10.1016/s0021-8502(99)00055-5

[5] Lei, H., Wang, L. Z., and Wu, Z. N, EHD turbulent flow and Monte-Carlo simulation for particle charging, J. Electrostat. 66 (2008) 130-141.

DOI: 10.1016/j.elstat.2007.11.001

[6] Launder, B. E., and Spalding, D. B, The numerical computation of turbulent flow, Comput. Method. Appl. M. 15 (1974) 269-289.

[7] Lei, H., Wang, L. Z., and Wu, Z. N, Applications of upwind and downwind schemes for calculating electrical conditions in a wire-plate electrostatic precipitator, J. Comput. Phys. 193 (2004) 697-707.

DOI: 10.1016/j.jcp.2003.08.016

[8] Patankar, S. V, Numerical heat transfer and fluid flow. Hemisphere publishing corporation, Washington, (1980).

[9] Sommerfeld, M, Validation of a stochastic Lagrangian modelling approach for inter-particle collisions in homogeneous isotropic turbulence, Int. J. Multiphas. Flow. 27 (2001) 1829-1858.

DOI: 10.1016/s0301-9322(01)00035-0

[10] Wassen, E., and Frank, T, Simulation of cluster formation in gas-solid flow induced by particle-particle collisions, Int. J. Multiphas. Flow. 27 (2001) 437-458.

DOI: 10.1016/s0301-9322(00)00028-8

[11] Oesterle, B., and Petitjean, A, Simulation of particle-to-particle interactions in gas-solid flows, Int. J. Multiphas. Flow. 19 (1993) 199-211.

DOI: 10.1016/0301-9322(93)90033-q

[12] Bird, G. A, Molecular gas dynamics and the direct simulation of gas flows. Clarendon Press, Oxford, (1994).

[13] Johnson, K. L., Kendall, K., and Roberts, A. D, Surface energy and the contact of elastic solids, P. Roy. Soc. A-Math. Phy. 324 (1971) 301-313.

[14] Yamamoto, T., and Velkoff, H. R, Electrohydrodynamics in and electrostatic precipitator, J. Fluid Mech. 108 (1981) 1-18.

DOI: 10.1017/s002211208100195x

[15] Leonard, G. L., Mitchner, M., and Self, S. A, An experimental study of the electrohydrodynamic flow in electrostatic precipitators, J. Fluid Mech. 127 (1983) 123-140.

DOI: 10.1017/s0022112083002657

[16] Kildeso, V. K., Bhatia, L. L., Johnson, E., and Johansen, A, An experimental investigation for agglomeration of aerosols in alternating electric fields, Aerosol Sci. Tech. 22 (1995) 422-430.

DOI: 10.1080/02786829508965341
