Particle Simulation of Slow-Wave System in Multi-Beam Traveling Wave Tube

Abstract:

A time-dependent particle code has been developed to simulate the motion and changing regularity of particles in multi-beam traveling wave tube. Magnetic focusing and interaction models of multi-beam traveling tube were established, and static magnetic field was calculated. The process of bunching particles by periodic permanent magnetic focusing system and beam-wave interaction was also simulated. The results show that particle simulation can really reflect the motion of particles in multi-beam traveling wave tube, which can provide some references for particle study of traveling wave tube.

• Periodical: Applied Mechanics and Materials (Volumes 155-156)
• Pages: 381-385
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.155-156.381
• Online since: February 2012
• Authors: Ze Lun Li, You Jun Huang, Zhi Cheng Huang
• Keywords: Multi-Beam, Numerical Simulation, Particle Code, Traveling Wave Tube

References

[1] Y.G. Ding, B. Shen and S.M. Shi: IEEE Trans. on Electron Devices Vol. 25 (2005), p.889.

[2] J.D. Wilson and C.L. Kory: IEEE Trans. on Electron Devices Vol. 42 (1995), p. (2015).

[3] E.A. Gelvich: Radiotekhnika Vol. 8 (2002), p.21.

[4] Z.Q. Bao and H. Deng: Journal of Electron Devices Vol. 6 (2004), p.274.

[5] A.J. Christlieb, R. Krasny and J.P. Verboncoeur: IEEE Trans. on Plasma Science Vol. 32 (2004), p.384.

[6] S. Humphries, S. Russell and B. Carlsten: IEEE Trans. on Plasma Science Vol. 33 (2005), p.882.

[7] R.W. Hockney and J.W. Eastwood: Computer simulation using particles (McGraw-Hill 1981).

[8] D. Joseph: IEEE Trans. on Plasma Science Vol. 28 (2000), p.821.

[9] A.S. Gilmour: Principle of traveling wave tubes (Artech House 1994).
