Research of MEDM Pulse Power Based on the Non-Resonant Natural Oscillation

Abstract:

Aiming to discharge feebly, improving the frequency of MEDM power pulse is an ideal choice. But due to the influence of power resistor, capacitor, inductor with stray capacitance and stray inductance, increasing the higher pulse power frequency met bottleneck. Through the analysis of MEDM discharging circuit and routes, this paper puts forward the theory of not using components, but depending on the natural oscillation of MEDM machine tools and connection line to make MEDM pulse power. Through theoretical calculation and simulation, the oscillation period of discharging circuit can be controlled in 1.5ns, and the pulse width can be less than 750 Ps. It provides theoretical support for making picosecond pulse power and nanometer manufacturing with MEDM.

• Periodical: Applied Mechanics and Materials (Volumes 157-158)
• Pages: 822-826
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.157-158.822
• Online since: February 2012
• Authors: Shu Fa Sun, Shi Chun Di, Dong Bo Wei, Zhao Long Li
• Keywords: MEDM, Non-Resonant Natural Oscillation, Picosecond, Pulse Power

References

[1] Liu Jinchun, Zhao Guji, Unconventional Machining,. Beijing: Mechanical industry press, 1997, p.1 – 29.

[2] Li Wenzhuo. MEDM system and related technology research, Harbin: Harbin institute of technology, (2002).

[3] FANG Tianshen, DONG Xueyi. Difference between Harmonic Resonance and Non-resonant Natural Oscillation of LC-series Circuit, Journal of Xinyang Normal University, Vo. l 20 No. 4 Oct. (2007).

[4] Zhang Wenjuan. How to use an oscilloscope probe, Journal of Astronautic Metrology and Measurement, vol. 1, Jan. 2007, pp.54-59.

[5] Qin Cenghuang. Electrotechnics, Beijing: Higher Education Press, 2004, pp.76-84.
