Effect of Interface States on the Properties of a-Si:H/c-Si Heterojunction Solar Cells Based on Solar Materials

Abstract:

The effect of the interface states on the properties of (p+) a-Si:H/(n) c-Si heterojunction solar cells is studied by a set of simulations. The results show that there is almost no effect on the short-circuit current. At very low interface states, there is almost no effect on the open-circuit voltage VOC and the fill factor FF, and then the conversion efficiency. Although, at high interface states, VOC decreases due to the decrease of the excess minority carrier density at the c-Si neutral region and the increase of the effective interface recombination velocity at the heterojucntion interface, which also results in the decrease of FF. In particular, at very high interface states, the hole transport is limited by the interface potential barrier, which results in S-shaped J–V characteristics and low fill factors. As a result, the conversion efficiency decreases with interface states increasing at high interface states.

You might also be interested in these eBooks

Solar Cells: Research and Development of Solar Cells

View Preview

Applied Mechanics, Materials, Industry and Manufacturing Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 164)

Pages:

158-161

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.164.158

Citation:

Cite this paper

Online since:

April 2012

Authors:

Chun Liang Zhong, L.E. Luo, Y.Q. Xia

Keywords:

a-Si:H/c-Si Heterojunctions, Interface State, Solar Cell

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y. Tsunomura, Yukihiro Yoshimine, Mikio Taguchi, et al : Sol. Energy Mater. Sol. Cells Vol. 93 (2009), pp.670-673

Google Scholar

[2] E. Yablonovitch, D. L. Allara, C. C. Chang: Phys. Rev. Lett. 57(1986), p.249

Google Scholar

[3] Y.J. Song, W.A. Anderson: Sol. Energy Mater. Sol. Cells Vol. 64 (2000), pp.241-249

Google Scholar

[4] T.H. Wang, E. Iwaniczko, M.R. Page, et al : Thin Solid Films Vol. 501 (2006), p.284–287

Google Scholar

[5] Sang-Kyun Kim, Jeong Chul Lee, Seong-Ju Park, et al: Sol. Energy Mater. Sol. Cells Vol. 92 (2008), p.298–301

Google Scholar

[6] K.V. Maydell, L. Korte, A. Laades, et al: J. Non-Cryst.Solids Vol. 352 (2006), p.(1958)

Google Scholar

[7] For AMPS-1D please see :http ://www. emprl . psu. Edu/amps

Google Scholar

[8] Madhumita Nath, P. Chatterjee, J. Damon-Lacoste, P. Roca i Cabarrocas: J. Non-Cryst. Solids Vol. 103(2008), p.034506

Google Scholar

[9] C. L. Zhong: A Dissertation for the Degree of Doctor of Philosophy [D] (2011)

Google Scholar

[10] C. L. Zhong, R. H. Yao, K. W. Geng: J. Phys. D: Appl. Phys. Vol. 43 (2010), p.495102

Google Scholar

[11] P. J. Rostan, U. Rau, V. X. Nguyen, T. Kirchartz, M. B. Schubert, J. H. Werner: Sol. Energy Mater. Sol. Cells Vol.90 (2006), p.1345

Google Scholar
