Influence Analysis of Mortar Elastic Modulus to CRTS III Slab Track Vertical Dynamic Response

Abstract:

A train-CRTS Ⅲ slab track coupling dynamic model was proposed to study the dynamic performance of the system. Rail was modeled as space beam element. Both slab and HGT layer were modeled as plate element respectively. The vertical and lateral connections between rail, slab, HGT layer, and subgrade were modeled as spring-damper element. The vibration matrix equation of the system was established on the basis of the principle of the total potential energy with stationary value in elastic system dynamics and the rule of “set-in-right-position” for formulating system matrices. The influence of mortar elastic modulus to CRTS Ⅲ slab track vertical dynamic response was calculated when the train runs at 350 km/h. The results show that the larger of mortar elastic modulus, the faster the vibration between rail and slab decays, and the slower the vibration between slab and HGT layer decays.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 314-317
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.314
• Online since: May 2012
• Authors: Zhi Ping Zeng, Xue Song Wang, Wen Rong Chen, Guang Cheng Long
• Keywords: CRTS III Slab Track, Elastic Modulus, Finite Element Method (FEM), Mortar, Vertical Vibration

References

[1] Huawu He. Ballastless track shall be developed in great efforts on Chinese passenger dedicated lines[J]. Chinese Railways, 2005, 44(1): 11-15(in Chinese)

[2] Qingyuan Xu, Xujiu Zhang. Longitudinal forces characteristic of Bogl longitudinal connected ballastless track on high-speed railway bridge [J]. Journal of Central South University (Science and Technology), 2009, 40(2): 526-532(in Chinese)

[3] Qingyuan Zeng, Ping Yang. The "set-in-right-position" rule for forming structural matrices and the finite truss element method for space analysis of truss bridge [J]. Journal of the China Railway Society, 1986, 8(2): 48-59(in Chinese)

[4] Qingyuan Zeng, Ping Lou, Jun Xiang. The principle of total potential energy with stationary valve in elastic system dynamics and its application to the analysis of vibration and dynamic stability[J]. Journal of Huazhong Universtiy of Science & Technology: Urban Science, 2002, 19(1): 7-14

[5] Dejian Li. Dynamic anslysis of train-track space - coupling time-varying system [D]. Changsha: Changsha Railway University, 1996(in Chinese)

[6] Kaller J. J. On the rolling contact of two elastic bodies in the presence of dry firciton[D]. Delft: Delft University of Technolgy, 1967.
