Optimization Simulations of Support System by Composite Soil-Nail Retaining Structure

Abstract:

Mechanism of composite pre-reinforced micro pile soil-nail and pure soil-nail retaining structure in foundation-pit engineering are analyzed in this paper through general three dimension nonlinear numerical simulation software. Research contents include whole construction process simulation of construction such as excavation by steps, piles and soil-nail installation and panel manufacture etc. By the comparison of mechanical characteristics between the pure soil-nail and composite soil-nail retaining structures in the same slope engineering example, differences of tension distribution range of soil layer, deformation features, mechanical characteristics of support and axial force distribution along nails etc. are analyzed. Research results are verified by in-site projects and measured data. The action mechanism and working performance of composite soil-nail retaining support are also systematically studied and theoretical basis can be provided in the similar application.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 863-868
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.863
• Online since: May 2012
• Authors: Jian Hua Huang, Guang Song, Er Xaing Song
• Keywords: Composite Soil Nail, Optimization Simulation, Pre-Reinforced Micro Pile, Retain Structure

References

[1] Chen Z. Y. , Cui J. H. , Applications of soil nail reinforcement in foundation pit engineering (2nd ed.). Beijing: Chinese construction industry press，2000.

[2] Song E.X., Chen Z. Y., Soil nail supporting and FEM analysis, Engineering investigation, 1996.2: 1-6.

[3] ZHANG Ming-ju, SONG Er-xiang. Finite element analysis of deformation performance of soil nailing [J]. China Civil Engineering Journal, 1999.12, Vol.32(6): 59-63.

[4] SONG Er-xiang, QIU Yue. Finite element analysis of composite soil nailing for excavation support [J]. Rock and Soil Mechanics, 2001.9, Vol.22(3):241-245.

[5] WU Jun, ZHENG Quan-ping, WU Xiang-yun. Numerical simulation in finite element and engineering application of compound soil nail support technology [J]. Chinese Jounal of Geotechnical Engineering, 2005.4, Vol. 27(4): 388-393.

[6] Er-xiang. Three Dimensional Nonlinear Finite Element Analysis on Composite Bracing of Anchor Rods with Soil Nailing for Deep Excavation [J]. Geotechnical Investigation &Surveying, 2001(6): 1-4.)

[7] Qin S. Q. , Jia H. et al. Numerical simulations of the deformation and failure in the pre - stressed soil - nailed reinforcement structure [J]. Rock and Soil Mechanics, 2005.9: 1356-1362.

[8] GUO Hong-xian, SONG Er-xiang, CHEN Zhao-yuan. Analysis of nail tensile forces during construction of soil nailing [J]. Rock and Soil Mechanics, 2008.9 Vol.29(9): 2463-2468.

[9] WANG Yuanyuan, QIN Siqing. Comparison of soil nail and composite soil nail reinforcement structures using numerical simulations [J]. Journal of Engineering Geology, 2006.02: 271-275.
