Mesh Generation for Arch Dam Abutment Slip Block Based on Virtual Grid

Abstract:

Abstract. In order to generate mesh for arch dam abutment slip block automatically, virtual grid method is proposed based on grid-based automatic generation algorithm. The proposed algorithm avoids generating initial grid in one time, but intersects the model with a series of plane sections firstly. Then form initial grid by using vector intersection method for adjacent sections. By modifying initial grid, a layer of mesh is formed. The algorithm proposed can better adapt to complex topography and generates hexahedral meshes for the block of arch dam abutment automatically. The method can present data for limit equilibrium analysis and numerical calculation method such as finite element method. Based on original topography and structural plane data, the automatic identification, generation and meshing of arch dam abutment block is accomplished.

• Periodical: Applied Mechanics and Materials (Volumes 170-173)
• Pages: 1954-1961
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.170-173.1954
• Online since: May 2012
• Authors: Xi Kang Liu, Jian Hai Zhang, Rong Gang Yin, Qiong Yang
• Keywords: Abutment Slip Block, Automatic Mesh Generation, Grid-Based Approach, Hexahedral Mesh, Structural Plane

References

[1] S.T. Wu, W.G. Zhao, C. Zhen: submitted to Advances in Science and Technology of Water Resources (2007), In Chinese

[2] L.L. Huang, G.Q. Zhao, X.W. Ma: submitted to Journal of Plasticity Engineering (2009), In Chinese

[3] H.M. Jiang, R.G. Liu Z.J. Wang: submitted to Journal of Plasticity Engineering (1998), In Chinese

[4] W.R. Quadros, K.Shimada, S.J. Owen: submitted to Engineering with Computers (2004)

[5] T.D. Blacker, R.J. Myers: submitted to Engineering with Computers (1993)

[6] X.W. Ma, G.Q. Zhao, G.C. Wang: submitted to Computer Applications (2001) , In Chinese
