Accuracy Control Technique of Vertically Matching the Curved Steel Tower

Abstract:

For solving the technical problem of accuracy control during manufacturing and vertically matching the curved steel tower of the bridge, this paper studies the accuracy control technique about it, as project example with the world’s first curved steel tower of No.3 Nanjing Yangtze River Bridge in China. Emphatically research the linear control during manufacturing and vertically matching the tower. Advance the conception of the accuracy control and build up an appropriate “Accuracy Control System” (ACS). Expound the contents of accuracy control, procedure and controlling means. Stress the research on the definition of the reference system of the tower, accumulated height error control, accumulated axis bias error control and accumulated torsion error control. Finally, in accordance with the results of accuracy control, give implement principle and method of manufacturing and vertically matching the tower. The check results show that accuracy of the control meets the design requirements and the research results are practical and reliable.

• Periodical: Applied Mechanics and Materials (Volumes 170-173)
• Pages: 2917-2923
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.170-173.2917
• Online since: May 2012
• Authors: Min Wei Jiang, Xi Cheng
• Keywords: Accumulated Error, Accuracy Control, Cable-Stayed Bridge, Curved Steel Tower, Vertically Matching

References

[1] Huang teng, et al .. "Linear control research of the construction of north inlet part of No.2 Nanjing Yangtze River Bridge." Geotechnical Investigation & Surveying, No.6(2003), 57-59.

[2] Xiang Zhong-fu. "Construction and control techniques of the bridge." Construction and control techniques of the bridge, China Communications Press, Beijing, China(2001), 118-120.

[3] Wu Dong-cai, et al.. "The construction surveying of Yangtz-river road bridge of Wuhan." Urban Geotechnical Investigation & Surveying, No.3(1995), 13-18

[4] Huang Zhang-yu, Zhao Zhong-rong, etc. "The construction surveying of high tower pile in the second bridge of Nanjing."Jiangsu Surveying and Mapping, 23(1) (2000), 19-22.

[5] Li Kun. "Trigonometric Leveling in Construction of SuperBridge." Journal of Changsha University of Electric Power (Natural science), No.3 (2005), 88-91.

[6] Hua Xi-sheng and Huang teng. "The technique and application of precision survey." The application of precision survey technique In the projects, Hohai University Press, Nanjing, China (2002), 247-270.

[7] Xia Gui-yun. "Theory of the calculation of the large-span bridge structures." Calculation of cable stayed bridge. China Communications Press, Beijing, China (2002), 75-86.
